Cost-Effective, Reliable and Secure Access Layer Switches J9782A
The Aruba J9782A 2530 Switch Series provides security, reliability, and ease of use for enterprise edge, branch office, and SMB deployments.
Fully managed switches deliver full Layer 2 capabilities with optional PoE+, enhanced access security, traffic prioritization, sFlow, and IPv6 host support.
Right size deployment with choice of 8-, 24-, and 48-port models available with Gigabit or Fast Ethernet ports, and optional PoE+.
Power savings with fanless models, Energy Efficient Ethernet (IEEE 802.3az), and ability to disable LEDs and enable port low power mode.
Delivers consistent wired/wireless user experience with unified security and management tools such as ClearPass Policy Manager, AirWave and cloud-based Central. Provides optimal configuration automatically when connected to Aruba J9782A APs for PoE priority, VLAN configuration, and rogue AP containment.
Security and Quality of Service (QoS) J9782A
The Aruba J9782A 2530 Switch Series supports flexible authentication methods including Local MAC, 802.1X, and MAC and Web for greater policy-driven application security.
Advanced denial of service (DOS) protection, such as DHCP Protection, Dynamic ARP protection, and Dynamic IP lockdown, enhance security. Flexible traffic controls include ACLs and QoS.
Traffic prioritization with IEEE 802.1p allows real-time traffic classification with support for eight priority levels mapped to either two or four queues using weighted deficit round robin (WDRR) or strict priority (SP).
Defend your IPv6 network with DHCPv6 Protection.
Simple Deployment and Management J9782A
The Aruba J9782A 2530 Switch Series supports a choice of management interfaces with Web GUI, command-line interface (CLI), and SNMP with either console or micro USB ports.
Quiet operation with fanless and variable speed fan models.
Flexible deployment with wall, table, and rack mounting options.
Zero touch provisioning (ZTP) provides quick and painless deployment at locations with few or no technical resources.
Single View of the Network J9782A
The Aruba J9782A 2530 Switch Series supports Aruba ClearPass Policy Manager for unified and consistent policy between wired and wireless users and simplifies implementation and management of guest login, user onboarding, network access, security, QoS, and other network policies.
Supports Aruba J9782A AirWave network management software to provide common platform for zero touch provisioning management and monitoring for wired and wireless network devices.
RMON and sFlow provide advanced monitoring and reporting capabilities for statistics, history, alarms, and events.
Aruba J9782A Central's cloud-based management platform offers simple, secure, and cost effective way to manage switches.
Supports both cloud-based Central and on-premise AirWave with the same hardware ensuring change of management platform without ripping and replacing switching infrastructure.
Specification J9782A:
| Product Name |
Aruba 2530 24 Switch |
| Manufacturer Part Number |
J9782A#ABA |
| Product Type |
Ethernet Switch |
| Manageable |
Yes |
| Ethernet Technology |
Fast Ethernet
Gigabit Ethernet
|
| Number of Total Expansion Slots |
2 |
| Product Family |
2530 |
| Media Type Supported |
Twisted Pair |
| Total Number of Network Ports |
26 |
| PoE (RJ-45) Port |
No |
| Expansion Slot Type |
SFP |
| Form Factor |
Rack-mountable
Desktop
Wall Mountable
|
| Power Source |
Power Supply |
| Layer Supported |
2 |
| Compatible Rack Unit |
1U |
| Number of SFP Slots |
2 |
| Uplink Port |
Yes |
| Shared SFP Slot |
No |
| Port / Expansion Slot Details |
24 x Fast Ethernet Network
2 x Gigabit Ethernet Uplink
2 x Gigabit Ethernet Expansion Slot
|
| Country of Origin |
China |
| Height |
1.8" |
| Width |
17.4" |
| Depth |
9.7" |
| Product Series |
2530 |
| Product Model |
2530-24 |
| Network Technology |
10/100Base-TX
10/100/1000Base-T
|
| Token Ring Port |
No |
| LRE Port |
No |
| USB |
Yes |
| Number of Network (RJ-45) Ports |
24 |
| Management Port |
Yes |
| Bypass |
No |
| Memory Technology |
DDR3 SDRAM |
| Flash Memory |
128 MB |
| Standard Memory |
256 MB |
