Detailed Specifications
HPE AM869A StorageWorks 8/40 SAN Switch Base (24-Port)
Overview
The HPE AM869A is an enterprise SAN traffic switch designed for data-centre storage fabrics and SAN edge environments where high-density Fibre Channel connectivity is required. The unit supports auto-sensing of 1/2/4/8 Gbps Fibre Channel SFPs across configurable port counts, providing a flexible platform for consolidated storage traffic. In its base configuration, it enables 24 ports (expandable to 40 ports via licence) within a 1U rack-mount chassis, delivering up to 680 Gbps aggregate full-duplex bandwidth and ISL trunking up to 64 Gbps for high-speed inter-switch links. It supports advanced features such as integrated routing, frame filtering, zoning, hot-swappable power and cooling, and full fabric management tools. This model fits into 19-inch racks, storage-array enclosures, and edge-fabric aggregation locations, and is well suited for organisations deploying virtualised storage, backup clusters or DR fabrics that require enterprise-grade Fibre Channel switching capabilities.
Key Features
Supports 24 active FC ports, scalable up to 40 via licence
Auto-sensing of 1/2/4/8 Gbps Fibre Channel speeds
Up to 680 Gbps aggregate full-duplex bandwidth in 1U
ISL trunking up to 64 Gbps for high-bandwidth inter-switch links
Hot-swappable redundant fans and power supplies
Technical Specifications
| Specification | Value |
|---|
| Brand | HPE |
| Part Number | AM869A |
| Product Type | StorageWorks 8/40 SAN Switch Base (24-Port Enabled) |
| Active Fibre Channel Ports | 24 ports |
| Maximum Ports | Up to 40 ports via licence upgrade |
| Supported Port Speeds | 1/2/4/8 Gbps Fibre Channel |
| Aggregate Device Bandwidth | Up to 680 Gbps full-duplex |
| ISL Trunk Bandwidth | Up to 64 Gbps |
| Form Factor (H × W × D) | 1.70 in × 16.88 in × 24.00 in (approx.) |
| Weight | Approx. 20.6 lbs (chassis with dual PSUs) |
| Airflow Direction | Back-to-front |
| Power Supplies | Dual redundant, hot-swappable |
| Operating Temperature | 0 °C to 40 °C |
| Maximum Frame Size | Up to 2,112 bytes |
| Supported Features | Zoning, frame filtering, integrated routing, ISL trunking |
| Compliance Standards | RoHS, WEEE |
