SonicWall NSa 2650 (02-SSC-2823) - Gen-7 3.5 Gbps Enterprise Firewall with VPN
Overview
The SonicWall NSa 2650, part number 02-SSC-2823, is a 1U rack-mount Gen-7 next-generation firewall designed for medium to large enterprise networks. It delivers 3.5 Gbps firewall throughput and 2 Gbps threat prevention, providing strong performance for encrypted traffic inspection, intrusion prevention, and application control.Equipped with 16 × 1 GbE RJ-45 ports, 2 × 10 GbE SFP+ uplinks, and console/management interfaces, the NSa 2650 offers flexible connectivity for WAN, LAN, and DMZ deployments. It supports up to 250 site-to-site VPN tunnels and high session counts, making it ideal for enterprise edges, branch aggregation, or secure remote connectivity.Running SonicOS 7, this appliance enables zero-touch provisioning, SD-WAN, and centralized management via Network Security Manager (NSM). It is suited for enterprises seeking high-performance security at the network perimeter while supporting multiple VPNs and high throughput requirements.
Key Features
3.5 Gbps firewall throughput × handles high-volume enterprise traffic efficiently.
2 Gbps threat prevention × deep packet inspection, IPS, anti-malware, and SSL/TLS decryption.
16×1 GbE + 2×10 GbE ports × flexible network connectivity and high-speed uplinks.
Supports 250 VPN tunnels × robust site-to-site and remote-access capabilities.
SonicOS 7 × centralized management, zero-touch deployment, SD-WAN ready.
High session capacity × supports large-scale concurrent SPI and DPI connections.
Technical Specifications
| Specification | Detail |
|---|
| Brand | SonicWall |
| Part Number | 02-SSC-2823 |
| Product Type | Next-Generation Firewall Appliance |
| Firewall Throughput | 3.5 Gbps |
| Threat Prevention Throughput | 2 Gbps |
| Management / OS | SonicOS 7.0 |
| Interfaces / Ports | 16×1 GbE RJ-45, 2×10 GbE SFP+, 1×Console, 1×Mgmt |
| VPN Support | Up to 250 site-to-site tunnels |
| Maximum DPI Connections | ~500,000 |
| SPI Connections (Max) | ~1,500,000 |
| New Connections / Sec | ~21,000 |
| Form Factor | 1U rack-mount |
| Power Consumption | ~120 W |
| Operating Temperature | 0-40 °C |
| Storage | 64 GB internal flash |
| Warranty / Service | Standard manufacturer warranty (varies by region) |
