HPE JL366A Aruba 8400X 6-port 40GbE/100GbE QSFP28 Advanced Module View larger

HPE JL366A Aruba 8400X 6-port 40GbE/100GbE QSFP28 Advanced Module



HPE JL366A Aruba 8400X 6-port 40GbE/100GbE QSFP28 Advanced Module


40 Gigabit Ethernet, 100GbE QSFP28, JL366A, HPE JL366A, HPE Aruba Advanced Module, HPE Aruba expansion module, JL366A access, JL366A review, JL366A manual, JL366A aruba, Aruba 8400X 6-port, network switch module

Detailed Specifications

Aruba JL366A network switch module 40 Gigabit Ethernet 8400X 6-port 40GbE/100GbE QSFP28 Advanced Module

Overview :

The past several decades in networking have been defined by static, closed networking solutions designed for the clientserver era. The Aruba JL366A CX 8400 campus core and aggregation switch is a game-changing solution offering a flexible and innovative approach to dealing with the new application, security and scalability demands of the mobile-cloud and IoT era. The Aruba JL366A CX 8400 also serves as a data center switch in either a core/aggregation or a leaf/spine topology.

The Aruba JL366A 8400 provides carrier class high availability with industry-leading line rate 10GbE/25GbE/40GbE/100GbE connectivity in a compact 8 slot chassis. It provides up to 19.2 Tbps of switching capacity based on a fully resilient design that includes redundant fabric, management, power and fans to create a resilient, highly available network that is ideal for the most demanding campus core and data center networks.

Key Features :

  • High performance 19.2 terabits per second switching (1.2Tbps/slot) capacity
  • Carrier-class high availability with Aruba JL366A Virtual Switching Extension (VSX), redundant management, power, and fabric
  • Aruba JL366AOS-CX enables automation and programmability using built-in REST APIs and Python scripts
  • Intelligent monitoring and visibility with Aruba JL366A Network Analytics Engine
  • Dynamic VXLAN with BGP-EVPN for deep segmentation in data center and campus networks
  • One touch deployment with the Aruba JL366A CX Mobile App
  •  Aruba JL366A NetEdit support for automated configuration and verification
  • Advanced Layer 2/3 feature set includes BGP, OSPF, VRF, and IPv6
  • Compact 8U chassis with high density, line rate 10GbE/40GbE/100GbE connectivity

Specifications :

Product Name Aruba JL366A 8400X 6-Port 40GbE/100GbE QSFP28 Advanced Module
Manufacturer Part Number JL366A
Product Type Expansion Module
Ethernet Technology 100 Gigabit Ethernet
Media Type Supported Optical Fiber
Network Technology 100GBase-X
Number of Total Expansion Slots 6
Expansion Slot Type QSFP28
Compatibility Aruba JL366A 8400X Switch Series
