Detailed Specifications
HPE JW759A Aruba 7240 (RW) Mobility Controller
Overview
The HPE JW759A is a 1-rack-unit mobility controller in the Aruba 7240 series, intended for campus core or large remote-site deployments where high density mobile clients, wireless access points and tunnelling services are required. It supports up to 2,048 managed access points and up to 32,768 concurrent client devices, enabling consolidated control of WLAN traffic, authentication, encryption, IPv4/IPv6 services, and firewall enforcement at multi-gigabit throughput. With four fixed 10 Gb/s SFP+ ports and two dual-personality ports (10/100/1000 BASE-T or SFP), it integrates fibre and copper connectivity to wired network backbones. The product supports clustering, high availability and broad network services making it fit for enterprise large-campus wireless systems. Remote management and lifecycle features allow integration into existing enterprise infrastructure.
Key Features
Supports up to 2,048 access points and 32,768 connected client devices.
Four 10 Gb/s SFP+ ports plus two dual-personality RJ-45/SFP ports for uplinks.
Up to 40 Gb/s wired throughput on the controller platform.
Supports IPv4/IPv6 routing, GRE/IPSec tunnels, wireless policy enforcement.
Field-replaceable Power Supply Unit (350 W) and designed for 1U rack-mount deployment.
Technical Specifications
| Specification | Value |
|---|
| Brand | HPE |
| Part Number | JW759A |
| Product Type | Aruba 7240 (RW) Mobility Controller |
| Access Point Capacity | Up to 2,048 APs |
| Concurrent Client Devices | Up to 32,768 devices |
| Wired Throughput | Up to ~40 Gb/s |
| Uplink Ports | 4 × 10 Gb/s SFP+ |
| Dual-Personality Ports | 2 × (10/100/1000 BASE-T or SFP) |
| Form Factor (H × W × D) | 1.73 in × 17.5 in × 17.5 in (approx) |
| Weight | ~16.43 lbs (~7.45 kg) |
| Power Supply Rating | 350 W AC |
| Typical Power Consumption | ~165 W |
| Operating Temperature | 0 °C to 40 °C |
| Supported VLANs | Up to 4,094 |
| GRE / IPSec Tunnels | Up to 32,768 tunnels |
| Supported AP Tunnels | Up to 16,384 tunneled ports |
| Warranty | 1 year parts & labour* |
