HPEP24251-001

MCX653105A-ECAT InfiniBand HDR100 / 100GbE QSFP56 Network Adapter

The HPEP24251-001 MCX653105A-ECAT card is a high-performance single-port InfiniBand HDR100 and 100 GbE QSFP56 Network Adapterbuilt for next-generation cluster and data center environments. With PCIe 4.0 ×16 (or ×8) host interface, it delivers ultra-low latency and full duplex 100 Gb/s throughput, ideal for HPC, storage clusters, virtualized applications, and AI workloads. This adapter supports both HDR InfiniBand and Ethernet modes over QSFP56, offering flexible deployment options. Compatible with HPEProLiant DL Gen10 Plus, Apollo, and Synergy servers, it ensures seamless integration while reducing CPU overhead with advanced offload engines.

Features

This HDR100/Ethernet adapter uses a QSFP56 port supporting DAC and AOC cables for flexible direct server or switch interconnects. It delivers line-rate throughput with sub-microsecond latency, making it well suited for high-performance messaging, inter-server traffic, and low-latency storage access scenariosEquipped with advanced offloading×including MPI tag matching, rendezvous, and adaptive routing×the adapter dramatically reduces CPU load during compute-intensive operations. Its PCIe Gen4 architecture supports maximal performance, while a low-profile bracket ensures compatibility with space-constrained server chassis

Advanced Options

This adapter is engineered for demanding network environments requiring high reliability and performance. It delivers full 100 Gb/s data rate with sub-microsecond latency when paired with HDR InfiniBand or 100 GbE switches, enabling real-time cluster communication. Reducing CPU overhead through intelligent offloading ensures maximum compute efficiency for workloads like AI training or distributed storage. The PCIe Gen4 architecture combined with Mellanox ConnectX-6 silicon supports both legacy and modern server platforms.

Product Key Features

• Single 100 Gbps QSFP56 port for HDR100 InfiniBand or Ethernet


• PCIe 4.0 ×16 (or ×8) host interface for high throughput


• Supports DAC and AOC cabling for flexible deployments


• Hardware offload engines: MPI, adaptive routing, rendezvous


• Ultra-low latency ideal for HPC, cluster, and storage links


• Compatible with HPEProLiant DL Gen10 Plus, Apollo XL, other platforms

---

Reliability & Performance

The card's low-profile form factor simplifies installation in rack servers or blades, while compliance with industry standards (RoHS, QSFP56, PCIe) guarantees interoperability and reliability in mission-critical operations. Certified for use in HPEProLiant and Apollo Gen10+ servers, it's tested for stable performance under sustained loads

Key Features :

• • 1 × QSFP56 port supporting HDR100 InfiniBand and 100GbE Ethernet

  • PCI Express Gen4 ×16 (×8 compatible) interface

  • Supports direct attach copper (DAC) and active optical cable (AOC)

  • Offload features: MPI tag matching, adaptive routing, rendezvous

  • Ultra-low sub-microsecond latency performance

  • Compact low-profile form factor for modern server chassis

  • Compatible with HPEProLiant Gen10 Plus, Apollo, Synergy platforms

  • Efficient throughput with minimal CPU overhead

  • Industry compliance: QSFP56, PCIe Gen4, RoHS

Specification	Details
Model Number	P24251-001
Product Type	InfiniBand HDR100 / 100 GbE Ethernet Network Adapter
Port Configuration	1 × QSFP56
Bus Interface	PCI Express Gen4 ×16 (×8 compatible)
Data Rate	100 Gbps full duplex
Supported Protocols	HDR100 InfiniBand, Ethernet 100Gb
Supported Cables	DAC and AOC via QSFP56
Form Factor	Low-profile plug-in card
Offload Features	MPI tag matching, rendezvous, adaptive routing
Latency	Sub-microsecond
Power Consumption	~15 W typical
Compatible Servers	HPEProLiant DL Gen10 Plus, Apollo XL, Synergy
Weight	~0.23 kg (0.5 lb)
Operating Temperature	0 °C to 55 °C
Compliance Standards	RoHS, QSFP56, PCIe Gen4 spec
