Detailed Specifications
ASUSTOR AMERICA AS7216RDX 16-Bay Rackmount Network Attached Storage
Overview :
The ASUSTOR AS7216RDX, branded as the LOCKERSTOR 16R Pro Gen2, is an enterprise-class rackmount NAS platform designed for virtualization, centralized storage, backup infrastructure, media production, and large-scale business deployments. Built for high availability and performance, it combines AMD Ryzen processing, ECC memory, and redundant power architecture in a rack-optimized design.
Powered by an AMD Ryzen 7 Pro 7745 processor featuring 8 cores and 16 threads, the system delivers enterprise-grade compute performance for virtual machines, containerized applications, file services, and intensive multi-user workloads. The NAS ships with 16GB ECC DDR5-4800 memory and supports expansion up to 192GB.
The platform supports sixteen 3.5-inch or 2.5-inch SATA drives and includes dual 10 Gigabit Ethernet ports alongside dual Gigabit Ethernet interfaces. PCIe Gen5 expansion slots enable deployment of high-speed networking, SAS controllers, and future infrastructure upgrades. Dual redundant 80 PLUS Platinum power supplies enhance availability in business-critical environments.
The AS7216RDX is intended for data centers, enterprise branches, virtualization hosts, surveillance storage, and backup repositories. It is not designed for entry-level NAS deployments or small office environments with limited storage requirements.
Key Features :
- AMD Ryzen 7 Pro processor with 8 cores and 16 threads
- Dual 10GbE plus dual Gigabit Ethernet ports
- Supports up to 192GB ECC DDR5 memory
- PCIe Gen5 expansion for future scalability
- Dual redundant 80 PLUS Platinum power supplies
Specifications :
| Specification | Details |
|---|
| Brand | ASUSTOR |
| Part Number | AS7216RDX |
| Product Type | 16-Bay Rackmount NAS |
| Processor | AMD Ryzen 7 Pro 7745 |
| CPU Cores / Threads | 8 Cores / 16 Threads |
| Maximum CPU Speed | Up to 5.3GHz |
| Memory | 16GB ECC DDR5-4800 |
| Maximum Memory | 192GB ECC DDR5 |
| Drive Bays | 16 × 3.5"/2.5" SATA HDD/SSD |
| Network Interfaces | 2 × 10GbE RJ-45, 2 × Gigabit Ethernet |
| Expansion Slots | PCIe 5.0 x8 and PCIe 5.0 x4 |
| M.2 Storage | 1 × M.2 NVMe PCIe 5.0 x4 SSD Slot |
| USB Ports | 4 × USB 3.2 Gen 1 Type-A |
| Power Supplies | Dual Redundant 80 PLUS Platinum |
| Form Factor | Rackmount NAS |
