Detailed Specifications
APC NSAC2101 NetShelter Aisle Containment Mutli Wall Panel 644 x 1232 mm Set of 5
Overview
The APC NSAC2101 is a kit of five multi-wall containment panels used in NetShelter aisle-containment systems. These panels are designed for data-centre or network infrastructure environments where containment needs to create a solid thermal barrier, but still allow for flexibility in installation. The 644 × 1232 mm size fits both ceiling-mounted and vertical-roof rack-mount configurations, and they are compatible with single, double, break-away, or curtain-style doors. This kit is ideal when building an aisle-containment system that must support modular configuration now and adapt to future changes.
Key Features
Includes 5 multi-wall panels (each 644 × 1232 mm) for containment flexibility.
Transparent panels help with visual inspection and light transmission.
Supports all second-generation NetShelter configurations × can be ceiling-mounted or installed in a vertical-roof architecture.
Compatible with different door types: single, double, break-away, or curtain.
Strong steel-framed corner supports (inside the panel) help maintain structure. (implicit in multi-wall design)
RoHS/REACH compliance and APC quality warranty. (typical for APC containment parts)
Technical Specifications
| Specification | Detail |
|---|
| Brand | APC by Schneider Electric |
| Part Number | NSAC2101 |
| Product Type | Aisle-Containment Panel Kit |
| Panel Dimensions | 644 mm × 1,232 mm (per panel) |
| Quantity in Kit | 5 panel |
| Material / Construction | Multi-wall (plastic) with internal supports |
| Finish / Color | Transparent / clear |
| Weight (Kit) | ~10 kg (total for all 5) |
| Compatibility | NetShelter 2nd-generation aisle containment (ceiling or vertical roof) |
| Warranty | 3-Year (as listed by some distributors) |
