Detailed Specifications
APC ACDC2201 - Adjustable Mounting Support (152-241 mm)
Overview
The APC ACDC2201 is a mounting-support bracket used in NetShelter aisle-containment systems. This adjustable support lets you bridge vertical gaps between rack frames or between the floor and containment rails, with a height range from 152 mm to 241 mm (6-9.5 in). It ensures your containment structure stays level and aligned, even when your ceiling or aisle geometry isn't uniform. Engineers deploying thermal containment (hot or cold aisles) use this post to maintain sealing integrity and avoid sagging or misalignment in row-based installations.
Key Features
Wide adjustability (152-241 mm): accommodates varying vertical gaps in containment systems.
Robust steel construction: provides strength and stability for secure containment assembly.
Easy repositioning: its adjustable height makes it easier to align rails or air-block connectors
Environmentally compliant: RoHS and REACH certified.
Long-term support: backed by a 5-year limited warranty per APC's policy.
Technical Specifications
| Specification | Detail |
|---|
| Brand | APC by Schneider Electric |
| Part Number | ACDC2201 |
| Product Type | Adjustable Mounting Support / Bracket |
| Adjustment Range | 152-241 mm (6-9.5 in) |
| Depth | ~900 mm (35.4 in) |
| Width | ~246 mm (9.69 in) |
| Height (min) | ~50 mm (1.97 in) |
| Weight | ~4.57 kg (10.1 lb) |
| Material / Finish | Steel, black finis |
| Environmental Compliance | RoHS, REACH |
| Warranty | 5-Year limited |
