Detailed Specifications
The ASUS ROG Strix X670E-F Gaming WiFi is an ATX mfotherboard designed for gaming and enthusiast desktop computers. Built around the AMD X670 chipset and AM5 socket, it supports compatible AMD Ryzen desktop processors and DDR5 memory. PCIe 5.0 support, four M.2 storage slots, advanced cooling features, and integrated wireless networking provide flexibility for performance-focused PC builds.
Key Features
- AMD AM5 platform: Supports compatible AMD Ryzen desktop processors, with exact CPU compatibility determined by the ASUS support list.
- DDR5 memory: Four DIMM slots support dual-channel DDR5 memory and AMD EXPO memory overclocking profiles.
- PCIe 5.0 support: Provides a PCIe 5.0 x16 expansion slot and PCIe 5.0 M.2 storage support for compatible components.
- Four M.2 slots: Supports high-speed NVMe storage, including PCIe 5.0 and PCIe 4.0 drives.
- Integrated connectivity: Includes Wi-Fi 6E, 2.5Gb Ethernet, USB Type-C connectivity, and SupremeFX audio.
Product Specifications
| Specification | Details |
|---|
| Brand | ASUS |
| Part Number / MPN | ROG STRIX X670E-F GAMING WIFI |
| Product Type | Desktop motherboard |
| Product Series | Republic of Gamers (ROG) Strix |
| Chipset | AMD X670 |
| CPU Socket | AMD AM5 |
| Processor Compatibility | Compatible AMD Ryzen desktop processors; check ASUS CPU support list |
| Form Factor | ATX |
| Dimensions | 30.5 × 24.4 cm |
| Memory Type | DDR5 |
| Memory Slots | 4 × DIMM |
| Maximum Memory Capacity | 192GB, according to current ASUS specifications |
| Memory Architecture | Dual-channel |
| Memory Overclocking | Up to DDR5-8000+ MT/s (OC), depending on configuration |
| Graphics Expansion | 1 × PCIe 5.0 x16 slot |
| Additional Expansion | 1 × PCIe 4.0 x16 slot operating at x4; 1 × PCIe 3.0 x1 slot |
| M.2 Storage | 4 × M.2 slots: 2 × PCIe 5.0 x4 and 2 × PCIe 4.0 x4 |
| SATA Connectivity | 4 × SATA 6Gb/s |
| Wireless Networking | Wi-Fi 6E |
| Bluetooth | Bluetooth 5.2 |
| Wired Networking | Intel 2.5Gb Ethernet |
| USB Connectivity | USB 3.2 Gen 2x2 Type-C, USB 3.2 Gen 2 Type-A and Type-C, USB 2.0 |
| Audio | ROG SupremeFX ALC4080 with Savitech SV3H712 amplifier |
| RGB Lighting | ASUS Aura Sync support |
| Manufacturer | ASUS |
DC Supplies Product Note
For the best compatibility, check the processor support list, BIOS requirements, memory compatibility list, and graphics card dimensions before purchasing. Memory overclocking speeds depend on the processor, installed memory modules, and system configuration.
Frequently Asked Questions
1. Which processors are compatible with this motherboard?
The motherboard uses the AMD AM5 socket and supports compatible Ryzen desktop processors. Consult ASUS's CPU support list for specific models and BIOS requirements.
2. Does the motherboard support DDR5 memory?
Yes. It has four DDR5 DIMM slots with dual-channel memory support and AMD EXPO compatibility.
3. Does it support PCIe 5.0 SSDs?
Yes. Two M.2 slots support PCIe 5.0 x4 storage, while two additional M.2 slots support PCIe 4.0 x4 drives.
4. What networking options are available?
The motherboard includes Wi-Fi 6E wireless networking and Intel 2.5Gb Ethernet.
5. What is the motherboard's form factor?
It uses the ATX form factor and measures approximately 30.5 × 24.4 cm.
