Ergotron 97-858-216 – SV Sit-Stand Combo Extender, Short, White
Overview
The Ergotron 97-858-216 SV Sit-Stand Combo Extender, Short adds an additional 9 inches (23 cm) of reach to compatible StyleView SV Combo Arms. The extender introduces a third pivot point, providing additional positioning flexibility for wall-mounted sit-stand workstations.
Technical Information
The 97-858-216 is designed as an extension component rather than a standalone monitor arm. It adds 9 inches (23 cm) of extension from the wall and incorporates a pivot mechanism with up to 180° of pan. An integrated cable-management channel snaps beneath the arm to help conceal connected cables.
The extender uses an aluminum and high-grade plastic construction with a durable, easy-to-clean exterior suitable for healthcare workstation environments.
Compatibility
The 97-858-216 is compatible with selected Ergotron StyleView SV Sit-Stand Combo Arms, including models 45-260-216, 45-266-216, 45-270-216, 45-271-216, 45-272-216 and 45-273-216. It can also be attached to an Ergotron Command Post using two 60-154-100 brackets.
Key Features
- Adds 9 inches (23 cm) of additional reach
- Creates a third pivot point for greater positioning flexibility
- Provides up to 180° of pan movement
- Integrated cable-management channel conceals cables beneath the arm
- White aluminum and high-grade plastic construction
Applications
The 97-858-216 is intended for healthcare, point-of-care and other workstation environments using compatible StyleView SV Combo Arms. It is useful where additional reach and positioning flexibility are required for wall-mounted sit-stand computer workstations.
DC Supplies Product Note
This listing applies specifically to Ergotron manufacturer part number 97-858-216, the white short SV Sit-Stand Combo Extender. It is an accessory component and does not function as a standalone monitor arm or workstation. Compatibility should be confirmed against the exact SV Combo Arm before deployment.
Specifications
| Specification | Details |
|---|
| Brand | Ergotron |
| Manufacturer Part Number | 97-858-216 |
| Product | SV Sit-Stand Combo Extender, Short |
| Product Type | Mounting Extension |
| Product Family | StyleView |
| Color | White |
| Extension | 9 inches (23 cm) |
| Additional Pivot Point | Third pivot point |
| Maximum Pan Angle | 180° |
| Construction | Aluminum and high-grade plastic |
| Cable Management | Integrated snap-fit cable-management channel |
| Compatible SV Combo Arms | 45-260-216, 45-266-216, 45-270-216, 45-271-216, 45-272-216, 45-273-216 |
| Command Post Compatibility | Two 60-154-100 brackets required |
| Included | 9-inch extender, pivot covers and Wall Track mounting brackets |
| Product Weight | 7.2 lb (3.2 kg) |
| Shipping Dimensions | 18 × 11 × 6 inches (44 × 27 × 14.5 cm) |
| Shipping Weight | 8.4 lb (3.8 kg) |
| Warranty | 5 years |
FAQs
What is the Ergotron 97-858-216?
The 97-858-216 is the white SV Sit-Stand Combo Extender, Short, designed to add reach and an additional pivot point to compatible StyleView SV Combo Arms.
How much additional reach does it provide?
The extender adds 9 inches (23 cm) of additional reach from the wall.
What does the third pivot point provide?
The additional pivot point provides greater flexibility when positioning the connected SV Combo Arm and workstation.
What is the maximum pan angle?
The extender provides up to 180° of pan movement.
Which SV Combo Arms are compatible?
Ergotron lists compatibility with 45-260-216, 45-266-216, 45-270-216, 45-271-216, 45-272-216 and 45-273-216.
Can the extender be mounted to a Command Post?
Yes. Ergotron specifies that two 60-154-100 brackets can be used to attach the extender to a Command Post.
Does it provide cable management?
Yes. A snap-fit cable-management channel installs beneath the arm to help conceal cables.
Is the SV Combo Arm included?
No. The 97-858-216 is an extender accessory. The compatible SV Combo Arm must be purchased separately.
What is the warranty?
Ergotron specifies a five-year warranty for the 97-858-216.
