Detailed Specifications
Eaton DDVD1727AM Safe-IT Adjustable Monitor Stand
Overview :
The Eaton DDVD1727AM (Tripp Lite Series) is a precision-placement full-motion single monitor desktop mount engineered with Safe-IT antimicrobial properties. Corporate procurement teams, office ergonomics managers, and home workstations deploy this heavy-duty mechanical mount to elevate monitors off the desk surface, optimizing ergonomic viewing angles while saving valuable square footage.
The arm is built with a rugged steel chassis equipped with an internal premium coil helical spring and a micro-adjustment adjustment handle to balance vertical placement fluidly. It accommodates most flat- or curved-screen monitors and HDTVs ranging from 17 to 27 inches, supporting hardware payloads up to 13.2 pounds. To promote a more hygienic workstation environment, the unit ships with specialized antimicrobial tape for the handle, designed to actively inhibit the proliferation of localized bacteria, mold, and mildew.
Occupying a standard desktop footprint, the mount secures tightly via desk clamp hardware or grommet structural paths. Full-motion joints allow the display to tilt, swivel, and rotate 180 degrees for portrait or landscape setups. Never exceed the rated 13.2-pound load parameter, as overloading the helical spring mechanism can cause the display to unexpectedly drop or sag over time.
Key Features :
Premium coil helical spring allows effortless vertical height adjustments.
Full-motion arm supports multi-angle tilting, swiveling, and 180° rotation.
Bundled antimicrobial tape wraps around the adjustment handle for sanitation.
Integrated rear routing slots neatly manage and hide device signal cords.
Solid steel frame provides robust anti-tip stability for curved or flat monitors.
Specifications :
| Property | Specification |
| Brand | Eaton (Tripp Lite Series) |
| Part Number | DDVD1727AM |
| Product Type | Full-Motion Desktop Monitor Mount |
| Product Line | Safe-IT |
| Screen Size Compatibility | 17" to 27" (43.2 cm to 68.6 cm) |
| Supported Display Types | Flat Panel, Curved Screen, Monitors, HDTVs |
| Maximum Weight Capacity | 13.2 lbs (6.0 kg) |
| VESA Mount Standards | 75 x 75 mm, 100 x 100 mm |
| Range of Motion (Tilt) | -45° to +45° |
| Range of Motion (Swivel) | -40° to +40° |
| Screen Rotation | 180° (Portrait / Landscape) |
| Mounting Options | Desk Clamp / Grommet Mount |
| Construction Material | Heavy-Duty Steel |
| Cable Management | Integrated Pass-Through Slot |
| Antimicrobial Protection | Yes (Handle Tape Included) |
