Detailed Specifications
HPE P74440-005 ProLiant MicroServer Gen11 E-2434
Overview
The HPE P74440-005 is a ProLiant MicroServer Gen11 designed for small offices, edge, or branch environments. It includes a quad-core Intel Xeon E-2434 processor and 32 GB of DDR5 standard ECC memory. The chassis supports four large-form-factor SATA drives for capacity and flexibility. It uses an Intel VROC-based software RAID controller and is powered by a 180 W external power adapter. Integrated ILO management enables remote control and monitoring.
Key Features
Intel Xeon E-2434, 4 cores / 8 threads
32 GB DDR5 unbuffered ECC memory
Supports 4 × 3.5″ LFF SATA drives (non-hot-plug)
Embedded Intel VROC SATA software RAID controller
Compact ultra-micro tower form factor with 180 W external power
Technical Specifications
| Specification | Details |
|---|
| Brand | HPE |
| Part Number | P74440-005 |
| Product Type | Server - Ultra Micro Tower |
| Processor Installed | Intel Xeon E-2434, 4 cores, 3.40 GHz |
| Processor Supported (Max) | Single-socket Xeon / Pentium (Gen11) |
| Memory Installed | 32 GB DDR5 ECC |
| Memory Slots | 4 UDIMM slots |
| Maximum Memory Supported | 128 GB DDR5 |
| Drive Bays | 4 × 3.5″ LFF (non-hot-plug) |
| Storage Controller | Intel VROC SATA (software RAID) |
| Network Adapter | 4 × 1 GbE BASE-T |
| Expansion Slots | 2: 1 × PCIe 5.0 (low profile) + 1 × PCIe 4.0 |
| Power Supply | 180 W external adapter, non-redundant |
