Detailed Specifications
NETGEAR RBK763S-100CNS - Tri-Band Mesh WiFi 6 System
Overview
The RBK763S is a mesh WiFi 6 system combining one router and two satellites for whole-home coverage. It is designed for network installers, integrators, and advanced home/office users who need seamless roaming and consistent throughput. It supports a dedicated tri-band backhaul to isolate node-to-node traffic from client data. It fits mid to large spaces (multi-room homes, small offices, branch environments). Management is via Orbi's app, web UI, or cloud integration, and it supports firmware and diagnostics control.
Key Features
AX5400 throughput (600 + 2400 + 2400 Mbps)
Dedicated 5 GHz backhaul band
Supports up to 75 concurrent devices
7 × Gigabit Ethernet ports across system
Technical Specifications
| Specification | Value |
|---|
| Brand | NETGEAR |
| Part Number | RBK763S-100CNS |
| Product Type | Tri-band Mesh WiFi 6 System |
| WiFi Standard | IEEE 802.11ax / 802.11ac / 802.11n / 802.11a/b/g |
| Aggregate Throughput | Up to 5.4 Gbps (600 + 2400 + 2400) |
| Processor | Dual-core 1 GHz (router & satellites) |
| Memory / Flash | 1 GB RAM + 4 GB eMMC NAND flash |
| Ethernet Ports (Router) | 1 × WAN + 3 × LAN (Gigabit) |
| Ethernet Ports (Each Satellite) | 2 × LAN (Gigabit) |
| Antennas | 4 internal high-performance antennas (per unit) |
