Detailed Specifications
NETGEAR RBE973S-100CNS - Orbi 970 Quad-Band Mesh System
Overview
The NETGEAR RBE973S-100CNS is a three-unit quad-band WiFi 7 mesh system (roRBE973S-100CNSuter + two satellites), intended to deliver high throughput and wide coverage in homes or small offices. It supports combined wireless speeds up to 27 Gbps using simultaneous 6 GHz, dual 5 GHz, and 2.4 GHz bands with dedicated backhaul. Each unit is furnished with multi-gig Ethernet ports to integrate wired devices or extend wired backhaul. This system is suited for large residences or dense environments needing full coverage across multiple floors. Management and configuration are done through the Orbi mobile app and built-in web interface.
Key Features
Simultaneous quad-band WiFi 7 (16 spatial streams)
Dedicated backhaul over 5 GHz-1 + 6 GHz
Multi-gig Ethernet ports on all units
Coverage up to 10,000 sq ft (system)
| Attribute | Specification |
|---|
| Brand | NETGEAR |
| Part Number | RBE973S-100CNS |
| Product Type | Mesh WiFi 7 System (Router + 2 Satellites) |
| Wireless Standard | IEEE 802.11be (WiFi 7) |
| Frequency Bands | Quad-band (2.4 GHz + 5 GHz-1 + 5 GHz-2 + 6 GHz) |
| Max Wireless Speed | 27 Gbps combined (11,530 + 8,647 + 5,765 + 1,147 Mbps) |
| Router Internal Memory | 2 GB RAM / 4 GB flash |
| Processor (Router) | Quad-core 2.2 GHz |
| Antennas | 12 internal high-performance antennas per unit |
| Wired Ports (Router) | 1 × 10 Gig WAN, 1 × 10 Gig LAN, 4 × 2.5 Gig LAN |
| Wired Ports (Satellite) | 1 × 10 Gig LAN, 2 × 2.5 Gig LAN per satellite |
| Coverage Area (System) | Up to 10,000 sq ft |
| Device Support | Up to 200 connected devices |
| Mesh Backhaul Mode | Dedicated backhaul on 5 GHz-1 + 6 GHz bands |
