Detailed Specifications
Eaton Tripp Lite N785-H01-SFP - Hardened Gigabit Fiber to Ethernet Media Converter
Overview :
The Eaton Tripp Lite N785-H01-SFP is a hardened Gigabit Ethernet media converter designed to extend network connections over fiber optic cable. It supports 10/100/1000 Mbps speeds and features an open SFP port, allowing users to select the appropriate transceiver for their specific distance and fiber type requirements. This flexibility makes it suitable for various applications, including industrial environments and remote deployments. The device operates within a wide temperature range of -10°C to 60°C, ensuring reliable performance in challenging conditions. Additionally, it offers automatic MDI/MDI-X configuration, simplifying installation by eliminating the need for crossover cables. The N785-H01-SFP is housed in a durable aluminum case, providing protection against electromagnetic interference and physical damage. It also supports Link Fault Signaling (LFS) and Loop Back functions, enhancing network reliability and diagnostics. This media converter is compliant with the Federal Trade Agreements Act (TAA), making it eligible for GSA Schedule and other federal procurement contracts.
Key Features :
Open SFP Port: Supports various SFP transceivers for flexible fiber connections.
Wide Operating Temperature: Functions between -10°C and 60°C for diverse environments.
Automatic MDI/MDI-X: Simplifies setup by auto-configuring network connections.
Durable Housing: Aluminum case shields against EMI and physical damage.
Link Fault Signaling: Provides network status indicators for proactive management.
Specifications :
| Specification | Details |
|---|
| Brand | Eaton Tripp Lite |
| Part Number | N785-H01-SFP |
| Product Type | Hardened Gigabit Fiber to Ethernet Media Converter |
| Ethernet Port | 1 x RJ45 (10/100/1000 Mbps) |
| Fiber Port | 1 x SFP (open) |
| Power Input | 100-240 VAC, 50/60 Hz |
| Power Consumption | 1.80 W |
| Operating Temperature | -10°C to 60°C |
| Housing | Aluminum |
| Mounting Options | Wall or DIN rail |
| Link Fault Signaling | Yes |
| Loop Back Function | Yes |
| MDI/MDI-X Detection | Yes |
| LED Indicators | Power, Link, Activity |
| Compliance | TAA Compliant |
| Dimensions (H x W x D) | 0.92 x 2.91 x 4.3 inches |
| Weight | 0.536 lbs |
