Teltonika TSW110000010 5Port Gigabit Industrial Switch View larger

Teltonika TSW110000010 5Port Gigabit Industrial Switch

TSW110000010

New

In Stock

5‑Port Gigabit Industrial Switch

×




$54.60

Detailed Specifications

Teltonika TSW110000010  5Port Gigabit Industrial Switch

Overview

Teltonika TSW110000010 is an unmanaged Layer 2 Gigabit Ethernet switch engineered for industrial environments requiring high‑speed wired connectivity. It provides five 10/100/1000 Mbps RJ45 ports with auto MDI/MDIX for plug‑and‑play connectivity without configuration. The rugged aluminium housing and wide voltage range support deployments in cabinets, enclosures, and field installations. DIN‑rail and surface mounting options allow flexible integration into existing network infrastructure.

Key Features

• 5× 10/100/1000 Mbps RJ45 ports
• 10 Gbps switching capacity
• Wide 9–30 V DC input range
• Rugged aluminium housing

Technical Specifications

SpecificationDetails
BrandTeltonika
Part NumberTSW110000010
Product Type5‑Port Gigabit Industrial Switch
Ethernet Ports5× RJ45 10/100/1000 Mbps
Switching Capacity10 Gbps
MAC Address Table2048 entries
Jumbo FrameUp to 9216 bytes
Power Input9–30 V DC
PoE SupportPassive PoE via Port 1
HousingAluminium
Dimensions100×30×85 mm
Weight227 g
MountingDIN rail, surface
Operating Temp.−40 °C to 75 °C
