Detailed Specifications
Teltonika TSW100010001 Fast Ethernet Switch
Overview
The Teltonika TSW100010001 is an unmanaged Fast Ethernet switch built for engineers and technicians who need simple 10/100 Mbps connectivity without configuration. It provides eight RJ45 Fast Ethernet ports with auto-MDI/MDIX for plug-and-play expansion of wired LANs in small offices, branches, or industrial environments. The compact design supports desktop or DIN-rail mounting where unmanaged connectivity is sufficient and Gigabit throughput isn't required. This switch is suitable for connecting legacy devices, sensors, or access points in networks that operate at Fast Ethernet speeds.
Key Features
• 8× 10/100 Mbps RJ45 ports
• Unmanaged plug-and-play operation
• Auto-MDI/MDIX on all ports
• Compact industrial form factor
Technical Specifications
| Specification | Details |
|---|
| Brand | Teltonika |
| Part Number | TSW100010001 |
| Product Type | Unmanaged Fast Ethernet Switch |
| Port Count | 8× 10/100 Mbps RJ45 |
| Management | Unmanaged (no configuration) |
| Auto-MDI/MDIX | Yes, on all ports |
| Switching Capacity | 1.6 Gbps |
| Packet Forwarding Rate | 1.19 Mpps |
| VLAN Support | Not supported |
| Power Input | 12 V DC, 1 A adapter |
| Mounting | Desktop or DIN-rail |
| Dimensions | 200 × 100 × 30 mm (7.87 × 3.94 × 1.18 in) |
| Weight | ~0.30 kg (0.66 lbs) |
| Operating Temp. | 0 °C to 50 °C |
