Detailed Specifications
Teltonika SWM280000200 PoE+ Managed Switch
Overview
The Teltonika SWM280000200 is a managed Gigabit Ethernet switch designed for engineers and IT integrators who need reliable LAN switching with power-over-Ethernet support in enterprise and industrial networks. It provides 8 Gigabit RJ45 PoE+ ports with per-port power and two Gigabit SFP uplinks for fiber expansion. The unit supports Layer 2/Layer 2+ management and industrial protocol features for segmented and resilient local networks. It runs TSW-OS for configuration, monitoring, VLAN, QoS, security, and link aggregation capabilities.
Key Features
• 8× Gigabit PoE+ RJ45 ports
• 2× Gigabit SFP uplink slots
• Total PoE budget 120 W
• Layer 2/2+ manageability
Technical Specifications
| Specification | Details |
|---|
| Brand | Teltonika |
| Part Number | SWM280000200 |
| Product Type | Managed PoE+ Ethernet Switch |
| Ethernet Ports | 8× 10/100/1000 Mbps RJ45 PoE+ |
| SFP Slots | 2× 1 Gbps SFP |
| PoE Standard | IEEE 802.3af/at (PoE+) |
| PoE Power per Port | Up to 30 W |
| Total PoE Power Budget | 120 W |
| Switching Capacity | 20 Gbps |
| Packet Forwarding Rate | 14.88 Mpps |
| Management | TSW-OS with VLAN, QoS, LACP |
| Power Input | AC 100-240 V AC, 50/60 Hz |
| Operating Temp. | 0 °C to 50 °C |
| Dimensions | 280 × 44 × 180 mm (11.02 × 1.73 × 7.09 in) |
| Weight | 1.2 kg (2.65 lbs) |
