HPE JH145A Gigabit 24 Ports 4SFP Ethernet Switch View larger

HPE JH145A FlexNetwork 5510 HI Gigabit Switch (24×1 GbE + 4×10 GbE SFP+)

JH145A

New

Managed Layer 3 switch with 24x 1GbE, 4x...

×




Detailed Specifications

HPE JH145A FlexNetwork 5510 24G 4SFP+ HI Layer 3 Switch

Overview

The HPE JH145A FlexNetwork 5510 HI Layer 3 Switch is a robust, rack-mountable solution featuring 24 autosensing Gigabit Ethernet RJ-45 ports plus four 10 GbE SFP+ uplinks. Built for medium to large enterprise networks, the switch delivers reliable, high-throughput performance with advanced routing and security capabilities. Equipped with stacking support, IRF virtualization, dual power supply options, and comprehensive Layer 3 features including IPv4/IPv6, MPLS, and dynamic routing protocols, it supports scalable campus or data center edge deployments. With sub-5 µs latency at Gigabit speeds and up to 288 Gbps switching capacity, this switch is ideal for environments demanding low-latency, high-bandwidth connectivity.

Key Features

  • 24 Gigabit Ethernet and 4 SFP+ 10GbE ports for high-speed access.
  • 288 Gbps switching capacity ensures seamless data flow.
  • MACSec support on ports 1-8 enhances network security.
  • One expansion module slot for future scalability and upgrades.
  • Layer 3 routing capabilities for advanced network segmentation.

Specifications

SpecificationValue
Brand HPE
Part Number JH145A
Product Type Layer 3 Switch
Series FlexNetwork 5510 HI
Ports 24x 10/100/1000Base-T, 4x SFP+ 10GbE
Expansion Slots 1 (for optional modules)
Switching Capacity 288 Gbps
Throughput 214 Mpps
Latency (1000 Mb) < 5 µs
Latency (10 Gbps) < 3 µs
MAC Address Table Size 32768 entries
IPv4 Routing Table Size 32768 entries
IPv6 Routing Table Size 16384 entries
Dimensions (H x W x D) 1.72 x 17.32 x 14.17 inches
Weight 16.53 lbs
Memory (SDRAM) 2 GB
Flash Memory 512 MB
Packet Buffer Size 4 MB
Power Supply Slots 2 (1 minimum required, ordered separately)
Form Factor 1U Rack-mountable
