Detailed Specifications
Ruckus ICX8200-24ZP – 24-Port Multigigabit PoE++ Switch
Overview :
The Ruckus ICX8200-24ZP is a 24-port managed switch designed for enterprise edge deployments, offering multigigabit Ethernet connectivity with Power over Ethernet Plus Plus (PoE++). It supports 100/1000/2500 Mbps speeds on all ports, delivering up to 740W of PoE++ power, suitable for high-power devices like IP cameras and wireless access points. The switch includes 4 SFP28 ports for 25GbE uplink or stacking, enabling high-bandwidth aggregation and simplified network architecture. With a switching capacity of 320 Gbps and a forwarding capacity of 237 Mpps, it ensures efficient data handling for demanding applications. The ICX8200-24ZP is ideal for branch offices, campus networks, and edge locations requiring high-density PoE++ support and robust performance.
Key Features :
24× 100/100/1000/2500 Mbps PoE++ ports
4× 25 GbE SFP28 stacking/uplink ports
740W PoE++ power budget
Layer 2/3 feature support with VXLAN
Stackable up to 12 units
Specifications :
| Attribute | Specification |
|---|
| Brand | Ruckus |
| Part Number | ICX8200-24ZP |
| Product Type | Managed Multigigabit PoE++ Switch |
| Ports | 24× 100/1000/2500 Mbps RJ45 |
| Uplink Ports | 4× 25 GbE SFP28 |
| PoE Standard | IEEE 802.3bt (PoE++) |
| PoE Power Budget | 740W |
| Switching Capacity | 320 Gbps |
| Forwarding Capacity | 237 Mpps |
| Stacking Capacity | Up to 12 switches |
| Management Ports | 1× RJ45 (Out-of-band) |
| Console Ports | 1× USB Type-C, 1× RJ45 |
| Form Factor | 1U Rackmount |
| Dimensions (W x D x H) | 17.3" × 10.5" × 1.7" |
| Weight | 11.5 lbs |
