Detailed Specifications
RUCKUS ICX7850-32Q – Core 100 GbE Switch
Overview :
The RUCKUS ICX7850-32Q is a fixed-form high-capacity Ethernet switch designed for engineers deploying large aggregations or campus cores where 40/100 GbE connectivity and full line-rate performance are required. It provides a non-blocking switching capacity of up to 6.4 Tb/s, supporting high-density QSFP28 ports that can be used as native 100 GbE or broken out to 4×25 GbE links, enabling flexible server or aggregation deployments. The unit supports stacking of up to 12 switches with an aggregated stack bandwidth of 9.6 Tb/s, making it suitable for distributed core or spine-leaf architectures. It fits in data-center, campus core or aggregation racks and supports redundant hot-swappable power supplies and fans, as well as reversible airflow options to integrate with existing cooling strategies. It also supports advanced Layer 3 routing protocols (BGP, OSPF, VRF) and multi-chassis trunking (MCT), enabling it to integrate into complex, highly available network fabrics.
Key Features :
32 × 40/100 GbE QSFP28 ports, breakout support to 4×25 GbE
Up to 12-unit stack support with 9.6 Tb/s stacking bandwidth
6.4 Tb/s switching capacity with full line-rate forwarding
Hot-swappable dual power supplies and fans with reversible airflow
Specification :
| Specification | Value |
|---|
| Brand | RUCKUS |
| Part Number | ICX7850-32Q |
| Product Type | Ethernet switch |
| Switching Capacity (max) | 6.4 Tb/s (6400 Gb/s) |
| Number of QSFP28 Ports | 32 |
| Breakout Support | 4×10 GbE or 4×25 GbE per port group |
| 10 GbE SFP+ Ports (max) | 128 |
| 25 GbE SFP28 Ports (max) | 128 |
| Maximum Switches per Stack | 12 |
| Aggregate Stack Bandwidth (max) | 9.6 Tb/s (9600 Gb/s) |
| PoE/PoE+ Support | No |
| Dimensions (H×W×D) | 1.72 in × 17.32 in × 17.50 in |
| Weight | 20 lbs |
| Advanced Layer-3 Support | Static, RIP, OSPF, BGP, VRF |
| Reversible Airflow | Yes |
