Detailed Specifications
RUCKUS ICX7850-48F – Ethernet Switch / High-Performance Aggregation
Overview :
The RUCKUS ICX7850-48F is a fixed-form factor, 1-rack-unit Ethernet switch targeted at enterprise network engineers and IT infrastructure teams who require high throughput aggregation or core switching. It offers 48 SFP28 ports capable of 1/10/25 GbE, along with 8 QSFP28 ports supporting 40/100 GbE for uplinks or stacking, allowing consolidation of server, storage or campus aggregation traffic. The unit supports stacking of up to 12 switches with up to 9.6 Tb/s aggregate bandwidth, enabling a distributed chassis architecture across wiring closets or campus nodes rather than a single central chassis. Deployment fits data centre leaf/spine or campus core/aggregation layers, or high-density wiring closet aggregation. The switch integrates with RUCKUS SmartZone or cloud-based management frameworks, and supports advanced Layer 3 routing and stacking features for resilient, scalable networks.
Key Features :
48 × 1/10/25 GbE SFP28 downlink ports
8 × 40/100 GbE QSFP28 uplink/stacking ports
Supports up to 12-unit stack with ~9.6 Tb/s aggregate stacking bandwidth
Dual hot-swappable power supplies and reversible airflow option
Specifications
| Specification | Value |
|---|
| Brand | RUCKUS |
| Part Number | ICX7850-48F |
| Product Type | Ethernet switch (core/aggregation) |
| Switching Capacity (max) | 4,000 Gb/s |
| Downlink Ports | 48 × 1/10/25 GbE (SFP28) |
| Uplink/Stacking Ports | 8 × 40/100 GbE (QSFP28) |
| Stackable Units | Up to 12 units |
| Aggregate Stack Bandwidth | 9,600 Gb/s |
| PoE/PoE+ Support | No |
| Rack Height | 1U (1.72 in) |
| Width | 17.32 in |
| Depth | 17.50 in |
| Weight | 19.4 lbs |
| Operating Temperature | 0 °C to 45 °C (32 °F to 113 °F) |
| Supported Routing Protocols | Static, RIP; license may enable OSPF, BGP, VRF |
