Detailed Specifications
Epson V11HA99020 3LCD Laser Projector
Overview :
The Epson V11HA99020 (PowerLite 810E) is an OEM, extreme short-throw lamp-free laser projector engineered for corporate hybrid boardrooms, high-density academic lecture halls, and digital signage displays. AV integration specialists and enterprise procurement teams deploy this solid-state laser projection system to implement large-scale collaborative canvases. It resolves the problem of sightline obstructions, screen glare, and presenter shadows common with long-throw hardware.
Utilizing a premium 3-chip 3LCD optical engine alongside pixel-shifting 4K Enhancement Technology, the system outputs 5,000 lumens of continuous white and color brightness. The specialized 0.16 to 0.22 throw ratio lens projects a massive 160-inch diagonal display from less than a foot away from the wall surface. Its integrated laser light source eliminates mechanical lamp replacement cycles, operating continuously for up to 30,000 hours in eco mode while utilizing software-driven automated edge smoothing.
The device scales infrastructure flexibility across enterprise campuses, flexible huddle spaces, and multi-purpose training rooms. It installs directly onto wall brackets, mounts via low-profile ceiling plates, or operates from standard presentation carts to provide responsive, high-brightness imaging.
This projection system interfaces directly with network environments via integrated HDBaseT, dual HDMI ports, and enterprise-grade Wi-Fi protocols. It features built-in compatibility with Microsoft Teams Front Row layout options and standard Crestron or Extron control networks. Do not deploy this ultra-short-throw system on standard uneven wall surfaces without a dedicated Ambient Light Rejecting (ALR) frame screen, as extreme-throw optics amplify minor wall ripples.
Key Features :
5,000 lumens output guarantees bright, legible images in high ambient light
4K Enhancement technology delivers crisp data lines and detailed schematics
0.16 throw ratio lens produces a 100-inch image from inches away from walls
Laser light engine operates up to 30,000 hours without lamp replacements
Multi-aspect casting supports ultra-wide 21:9 and 16:6 corporate video setups
Specifications :
| Specification | Value |
| Brand | Epson |
| Part Number | V11HA99020 |
| Product Type | 3LCD Laser Projector |
| Light Source | Laser Phosphor Diode |
| Brightness | 5,000 Lumens (Color and White Output) |
| Native Resolution | 1080p with 4K Enhancement (Pixel-Shift) |
| Throw Ratio | 0.16:1 to 0.22:1 |
| Projection Size | 80 to 160 Inches |
| Interfaces | 2 x HDMI, 1 x HDBaseT, 1 x RS-232C, 2 x USB-A, 1 x USB-B, RJ-45 |
| Wireless Security | Integrated Wi-Fi, Miracast R2 Screen Mirroring |
| Aspect Ratios | 16:9 Native (Supports 16:10, 4:3, 21:9, 16:6) |
| Dynamic Contrast | Over 2,500,000:1 |
| Expected Source Life | 20,000 Hours (Normal) / 30,000 Hours (Extended Mode) |
| Operating Temperature | 32 °F to 104 °F (0 °C to 40 °C) |
