Dell P1425 Pro 14 Plus Portable Monitor is a 14-inch portable LED monitor with a WUXGA 1920 x 1200 display, IPS panel technology, 60Hz refresh rate, and 16:10 aspect ratio. It provides two USB-C ports with DisplayPort 1.2 Alt Mode and supports power pass-through up to 65W.
Display
The monitor uses an IPS panel with 1920 x 1200 maximum resolution, 7 ms GTG response time, 178° horizontal and vertical viewing angles, 400 cd/m² brightness, 1,500:1 native contrast ratio, and 100% sRGB color gamut. The display supports 16.7 million colors and has a 162 PPI pixel density.
USB-C Connectivity
The P1425 provides two USB-C ports supporting DisplayPort 1.2 Alt Mode, HDCP 1.4, and video up to 1920 x 1200 at 60Hz. The USB-C interface also supports power pass-through of up to 65W.
Adjustment and Mounting
The monitor includes an adjustable stand supporting tilt and portrait positioning. Dell specifies a 10° to 90° tilt range and a 100 x 100 mm VESA mounting standard. An auto-rotation sensor is also provided.
Key Features
- 14-inch WUXGA IPS display with 1920 x 1200 resolution
- 60Hz refresh rate and 7 ms GTG response time
- Two USB-C ports with DisplayPort 1.2 Alt Mode
- Up to 65W USB-C power pass-through
- 100 x 100 mm VESA mounting compatibility with tilt and portrait adjustment
Portable Design
The P1425 is designed as a portable flat-panel display with an anti-glare surface, narrow bezel, LED edgelight backlight, and 3H glass hardness. The monitor has a compact 4.60 mm panel depth and weighs approximately 0.57 kg without cables.
DC Supplies Product Note
When deploying the P1425 through USB-C, the connected host should provide compatible DisplayPort 1.2 Alt Mode functionality. Dell specifies two USB-C ports and support for up to 65W power pass-through, making the available host USB-C capabilities an important consideration for installation.
Specifications
| Specification | Details |
|---|
| Brand | Dell |
| Part Number / MPN | DELL-P1425 |
| Product Type | LED Monitor |
| Product Model | P1425 |
| Product Line | Pro Plus |
| Screen Size | 14 inches |
| Panel Technology | IPS |
| Screen Mode | WUXGA |
| Resolution | 1920 x 1200 |
| Refresh Rate | 60 Hz |
| Aspect Ratio | 16:10 |
| Response Time | 7 ms GTG |
| Brightness | 400 cd/m² |
| Native Contrast Ratio | 1,500:1 |
| Color Gamut | 100% sRGB |
| Color Support | 16.7 million colors |
| Pixel Density | 162 PPI |
| Pixel Pitch | 0.15708 mm x 0.15708 mm |
| Viewing Angle | 178° horizontal / 178° vertical |
| USB-C Ports | 2 |
| USB-C Video | DisplayPort 1.2 Alt Mode |
| Power Pass-Through | Up to 65W |
| HDCP | HDCP 1.4 |
| VESA Mount | 100 x 100 mm |
| Tilt Range | 10° to 90° |
| Operating Temperature | 0°C to 40°C |
| Panel Dimensions | 315.15 x 223.54 x 4.60 mm |
| Weight Without Cables | Approx. 0.57 kg |
FAQs
What resolution does the Dell P1425 support?
The P1425 supports 1920 x 1200 resolution at a 60Hz refresh rate.
What type of panel does the P1425 use?
The monitor uses an IPS panel with 178° horizontal and vertical viewing angles.
How many USB-C ports are available?
The P1425 has two USB-C ports supporting DisplayPort 1.2 Alt Mode and up to 65W power pass-through.
Does the monitor support VESA mounting?
Yes. The P1425 supports the 100 x 100 mm VESA mounting standard.
Does the P1425 support portrait positioning?
Yes. The adjustable stand supports portrait positioning and includes an auto-rotation sensor.
