Ergotron 24-194-055 – Neo-Flex Dual WideView WorkSpace, Two-Tone Grey
Overview
The Ergotron 24-194-055 Neo-Flex Dual WideView WorkSpace is a mobile dual-display workstation designed for applications requiring two monitors, an integrated worksurface and flexible height adjustment. The two-tone grey cart uses an open architecture with a dual-display crossbar, integrated keyboard/workspace area, CPU holder, cable storage and mobile casters.
The workstation provides a 20-inch (51 cm) height-adjustment range for seated or standing operation. Ergotron's Constant Force technology provides one-touch height adjustment, while the compact wheel-to-wheel base is designed for movement through small doorways and over thresholds.
Technical Information
The 24-194-055 supports two displays up to 22 inches each. Each LCD mount supports 6–14 lb (2.7–6.4 kg), with a combined display range of 12–28 lb (5.4–12.7 kg). The total load on the height-adjustment assembly is limited to 40 lb (18 kg), including the displays and contents placed on the worksurface and in the cable storage box.
The dual displays mount using VESA FDMI MIS-D 75/100 patterns with 75 x 75 mm and 100 x 100 mm hole patterns. Displays can be installed at five different height positions and are fixed at either a 3.5° or 8.5° upward angle; the dual-display mounts are not continuously tilt adjustable.
Compatibility
The 24-194-055 is configured specifically for two displays up to 22 inches each. Each display mount uses VESA MIS-D 75/100 mounting patterns. The rear CPU holder adjusts from 12 x 3 inches to 18 x 8.5 inches (30 x 8 cm to 46 x 22 cm) and supports up to 40 lb (18 kg).
The integrated worksurface measures 16.5 x 14 inches (42 x 36 cm) and includes a concealed mouse tray that can slide out on either the left or right side. The cart also provides a scanner holder, mouse holder and cable storage box for mobile computing workflows.
Key Features
- Exact Ergotron part number 24-194-055 in two-tone grey
- Dual-display support for two screens up to 22 inches each
- 20-inch (51 cm) Constant Force height adjustment for seated or standing use
- 6–14 lb (2.7–6.4 kg) display capacity per mount with VESA MIS-D 75/100 mounting
- Integrated worksurface, keyboard area, cable storage, CPU holder and four dual casters with two locking casters
Applications
The Ergotron 24-194-055 is suited to mobile dual-monitor computing, telemedicine, radiology and clinical PACS access, laboratories, manufacturing environments, distribution facilities, distance-learning installations and corporate workspaces. Its compact mobile platform supports workflows where dual displays need to move between locations.
DC Supplies Product Note
The 24-194-055 is a complete mobile workstation rather than a desktop monitor stand or standalone dual-monitor arm. Verify both display weight and VESA compatibility before deployment. The exact dual-display configuration is important because the related 24-189-055 is a single-display Neo-Flex WideView WorkSpace with different display specifications.
Specifications
| Specification | Details |
|---|
| Brand | Ergotron |
| Part Number | 24-194-055 |
| Product | Neo-Flex Dual WideView WorkSpace |
| Color | Two-tone grey |
| Display Configuration | Dual display |
| Typical Display Size | Two displays up to 22 in |
| Display Capacity | 6–14 lb (2.7–6.4 kg) per display |
| Combined Display Capacity | 12–28 lb (5.4–12.7 kg) |
| Height Adjustment | 20 in (51 cm) |
| Total Height-Adjustment Load | 40 lb (18 kg), including displays and worksurface/cable-storage contents |
| Display Rotation | 90° portrait/landscape |
| Display Tilt | Fixed 3.5° or 8.5° upward angle; not continuously tilt adjustable |
| VESA Mounting | MIS-D, 75/100; 75 x 75 mm and 100 x 100 mm |
| Worksurface | 16.5 x 14 in (42 x 36 cm) |
| Wheel-to-Wheel Base | 17 x 20.5 in (43 x 52 cm) |
| CPU Holder Capacity | 40 lb (18 kg) |
| CPU Holder Adjustment | 12 x 3 to 18 x 8.5 in (30 x 8 to 46 x 22 cm) |
| Casters | Four dual casters; two locking |
| Construction | Aluminum, high-grade plastic and powder-coated steel |
| Shipping Dimensions | 45.5 x 19.75 x 24 in (1156 x 502 x 610 mm) |
| Shipping Weight | 88 lb (40 kg) |
| Warranty | 3 years |
FAQs
What is the Ergotron 24-194-055?
The 24-194-055 is the Ergotron Neo-Flex Dual WideView WorkSpace, a mobile workstation configured for two displays.
How many monitors can the 24-194-055 support?
The workstation supports two displays, with a typical maximum display size of 22 inches per screen.
What is the monitor weight capacity?
Each LCD mount supports 6–14 lb (2.7–6.4 kg). The combined display range is 12–28 lb (5.4–12.7 kg).
Does the workstation provide height adjustment?
Yes. The workstation provides 20 inches (51 cm) of height adjustment using Ergotron Constant Force technology.
Can the monitors tilt?
The dual displays are installed at either a 3.5° or 8.5° upward angle. The dual-display mounts are not continuously tilt adjustable.
What VESA mounting pattern is supported?
The display mounts support VESA FDMI MIS-D 75/100 patterns, including 75 x 75 mm and 100 x 100 mm hole patterns.
Does it include a CPU holder?
Yes. The 24-194-055 includes a rear CPU holder adjustable from 12 x 3 inches to 18 x 8.5 inches, with a 40 lb (18 kg) capacity.
Does the workstation include a keyboard and mouse area?
Yes. It includes an integrated 16.5 x 14-inch worksurface/keyboard tray with a concealed mouse tray that can slide out from either the left or right side.
