Detailed Specifications
EXTREME NETWORKS 5320-48T-8XE - Layer 3 Universal Ethernet Switch
Overview
The EXTREME NETWORKS 5320-48T-8XE is an enterprise-grade, high-density edge connectivity switch custom-engineered for modern digital corporate infrastructure and campus wiring closets.This universal hardware platform resolves hardware-based vendor lock-in by supporting dual-persona firmware initialization, enabling network administrators to dynamically toggle operational environments depending on deployment targets. It establishes standard operational readiness for multi-tier branch offices and high-throughput corporate aggregation segments requiring robust line-rate security without latency degradation.
The structural deployment architecture centers on a fixed 1RU chassis containing 48 autosensing 10/100/1000BASE-T access ports paired with 8 multi-rate 1/10Gb SFP+ uplink sockets. This specific configuration is a non-PoE version designed strictly for data routing environments where external powered endpoint distribution is unnecessary or restricted. For scalable infrastructure expansion, two of the unpopulated SFP+ interfaces can be configured as native high-speed stacking interfaces, enabling administrators to bind up to eight 5320 series units into a single managed ring configuration operating at 40 Gbps aggregate stacking bandwidth.
Designed for automated network provisioning, the switch seamlessly registers with ExtremeCloud IQ out of the box, pulling and launching pre-configured management templates remotely without manual terminal setup.It features full hardware-based IEEE 802.1AE MACsec encryption capabilities across access and uplink paths to guarantee cryptographic protection on point-to-point links. Avoid deploying this hardware node in power-injection topologies requiring active 802.3at endpoint support, or in complex multi-path fabric rings that run VOSS/Fabric Engine software where native stacking functions are not supported by the underlying operating platform.
Key Features
Dual-persona boot support allows native execution of EXOS or VOSS software.
8 dedicated SFP+ ports deliver up to 80 Gbps of uplink capabilities.
Stacking flexibility aggregates up to eight chassis into a unified node.
Hardware-based MACsec encryption secures structural links across the enterprise.
Universal cloud orchestration streamlines remote deployment and central licensing.
Specifications
| Spec Parameter | Technical Data |
| Brand | EXTREME NETWORKS |
| Part Number | 5320-48T-8XE |
| Product Type | Layer 3 Universal Ethernet Switch |
| Chassis Form Factor | 1RU Rack-Mountable Hardware Profile |
| Primary Access Interfaces | 48 x 10/100/1000BASE-T Ports (Autosensing, Full/Half-Duplex) |
| High-Speed Uplinks | 8 x 1/10Gb SFP+ Unpopulated Ports (Last 4 Support 100Mb) |
| Integrated Stacking Capacity | Up to 8 Switches via 2 x SFP+ Stacking Ports (40Gb Stacking) |
| Core Switching Bandwidth | 256 Gbps Aggregate Fabric |
| Frame Forwarding Performance | 190.5 Mpps Line-Rate Execution |
| MAC Address Table Capacity | 32,000 Entries (Without Fabric Enabled) |
| Encryption Protocol Support | IEEE 802.1AE MACsec-Capable Access and Uplink Ports |
| Configuration Console Ports | 1 x Serial Console (RJ-45), 1 x USB Micro-B Console Port |
| Storage / Management Port | 1 x USB Type-A Interface for Flash/Firmware Management |
| Power Infrastructure | 1 x Fixed Internal AC Power Supply (95W Maximum Load) |
| Operational Environment | Commercial 32°F to 113°F (0°C to 45°C) Storage Up to 158°F |
