Detailed Specifications
Epson V11HA08620-N Ultra Short Throw Laser Projector
Overview :
The Epson V11HA08620-N (PowerLite 755F) is a commercial-grade, ultra-short-throw 3LCD laser projector designed specifically for digital signage, corporate presentation areas, and education spaces. AV engineering and procurement teams deploy this system to deliver high-impact, ambient-light-resistant video content in confined environments. By utilizing an advanced laser diode assembly, the hardware eliminates traditional lamp replacement cycles, stabilizing total cost of ownership (TCO) across enterprise installations.
Equipped with a true 3-chip 3LCD engine, the system delivers an equal 3,600 lumens of color and white brightness to produce vibrant, true-to-life images up to 120 inches diagonally at a native Full HD 1080p resolution.Its short-throw lens configuration features a 0.26:1 throw ratio, projecting oversized media assets from mere inches away from the mounting surface. This specialized placement path prevents presenter shadowing and direct optical interference while optimizing space utilization in retail end-caps or tight classrooms.
Engineered for adaptable installation, the chassis supports full 360-degree placement options, facilitating portrait-oriented storefront setups and geometric floor projection. Integrated networking utilities, including 5GHz dual-band wireless and Miracast, provide local and cloud-based content delivery pathways via Epson's diagnostic management suite, eliminating dedicated media players.
This platform is targeted exclusively for fixed commercial signage, spatial galleries, and architectural spaces. It must not be specified for high-end home theater setups requiring native 4K anamorphic lens conversions, or large-auditorium venues that demand long-throw motorized lens shifts, as its static short-throw design will fail to focus outside its specified 15.3-inch maximum throw boundary.
Key Features :
Ultra-short-throw 0.26 throw ratio eliminates shadows in tight spaces.
Solid-state laser light engine operates for 20,000 maintenance-free hours.
Balanced 3,600 lumens display rich color outputs under daylight lighting.
360-degree free orientation enables rapid portrait or landscape mounting.
Built-in edge blending combines multiple systems seamlessly into macro displays.
Specifications :
| Specification | Value |
| Brand | Epson |
| Part Number | V11HA08620-N |
| Product Type | Ultra Short Throw Laser Projector |
| Projection System | 3LCD, 3-Chip Technology |
| Native Resolution | Full HD 1080p (1920 x 1080) |
| Color & White Brightness | 3,600 Lumens |
| Contrast Ratio | Over 2,500,000:1 (Dynamic) |
| Light Source Type | Laser Diode |
| Light Source Life | 20,000 Hours (Normal) / 30,000 Hours (Extended) |
| Native Aspect Ratio | 16:9 (Supports 4:3, 16:10, 16:6, 21:9) |
| Throw Ratio Range | 0.26:1 to 0.36:1 |
| Input Interfaces | 3x HDMI, 2x VGA D-Sub 15-Pin, 1x RCA Composite Audio/Video |
| Control & Network Ports | 1x RJ-45 LAN, 1x RS-232C, 2x USB-A, 1x USB-B |
| Wireless Connectivity | Built-in 802.11a/b/g/n/ac (2.4 GHz & 5 GHz) + Miracast |
| Operational Power | 267W (Normal Mode) / 206W (Quiet Mode) |
