Detailed Specifications
Eaton B072-032-IP2 - 32-Port Cat5 Over IP KVM Switch
Overview :
The Eaton B072-032-IP2 is a 32-port Cat5 KVM switch designed for centralized management of multiple servers or computers over a secure IP connection. It enables IT administrators to control connected systems remotely through a web-based interface or local console. Ideal for enterprise data centers, server rooms, and remote branch offices, it provides reliable BIOS-level access for system maintenance. The switch integrates seamlessly with Eaton rack infrastructure and supports remote authentication protocols for secure management.
Key Features :
32 Cat5 RJ45 server ports
Dual redundant Ethernet ports
Local and remote KVM access
1U rackmount form factor
Specifications :
| Specification | Details |
|---|
| Brand | Eaton |
| Part Number | B072-032-IP2 |
| Product Type | Cat5 Over IP KVM Switch |
| Number of Ports | 32 RJ45 (Cat5) |
| Local Console | 1 x VGA, 2 x USB, 1 x PS/2 |
| Remote Users Supported | 2 simultaneous IP users |
| Video Resolution | Up to 1920 x 1080 @ 60 Hz |
| Network Interface | Dual 10/100/1000 Mbps Ethernet |
| Compatibility | Windows, Linux, UNIX, macOS |
| Authentication | LDAP, RADIUS, local user database |
| Encryption | 128-bit SSL, AES, and RSA |
| Form Factor | 1U rackmount |
| Dimensions (W x D x H) | 43.7 x 22.9 x 4.4 cm |
| Weight | 3.8 kg |
| Operating Temperature | 0°C to 40°C |
