Tripp Lite B070-016-19-IP2 - 16-Port KVM over IP 1U LCD Console
Overview
The Tripp Lite B070-016-19-IP2 is a rack-mounted KVM over IP console that integrates a 16-port KVM switch, 19-inch LCD display, keyboard, and touchpad into a single 1U unit. It is deployed by data center and network engineers for centralized management of multiple servers from both local rack access and remote IP-based sessions. It addresses the need for consolidated console access without requiring individual peripherals per device.
The unit supports up to 16 connected servers using Cat5e/6 cabling with compatible server interface units, enabling structured cabling within racks and reducing cable bulk. It provides simultaneous access for up to three users (one local and two remote), with remote connectivity delivered over dual Ethernet interfaces for redundancy. Virtual media functionality allows remote mounting of ISO files, enabling OS installation and maintenance without physical presence.
Designed for deployment in standard 19-inch racks, the console occupies 1U of space and is typically installed in MDF or data center environments where multiple servers require BIOS-level access. The integrated LCD console eliminates the need for external crash carts and enables direct rack-side interaction when required.
The system supports both IPv4 and IPv6 networking and integrates with authentication systems such as RADIUS and LDAP for centralized access control. It provides encrypted remote sessions using HTTPS and AES-based security, aligning with controlled access requirements in managed IT environments.
In a practical deployment, the KVM is mounted at the top or middle of a rack, connected to multiple servers via Cat6 cabling and interface modules. Administrators can access systems remotely for troubleshooting, firmware updates, or OS provisioning, while still retaining local access via the pull-out console.
This device should not be used in environments requiring high-resolution local display beyond its panel limits or where direct digital video interfaces are required without conversion. It also depends on external interface modules (SIUs), making it unsuitable for deployments without structured cabling or where direct KVM cabling is preferred.
Key Features
• 16-port Cat5 KVM switching for rack server control
• Integrated 19-inch LCD console with keyboard and touchpad
• Dual LAN ports for redundant IP remote access
• Virtual media support for remote OS and file mounting
• Multi-user access with 1 local and 2 remote sessions
Specifications
| Specification | Details |
|---|
| Brand | Tripp Lite (Eaton) |
| Part Number | B070-016-19-IP2 |
| Product Type | KVM over IP Rack Console |
| Number of Ports | 16 |
| KVM Technology | Digital (Cat5-based) |
| Supported Users | 3 simultaneous (1 local, 2 remote) |
| Display Size | 19-inch LCD |
| Resolution (Local) | 1366 × 768 |
| Resolution (Remote) | Up to 1920 × 1080 |
| Connectivity | Cat5e/6 with SIUs |
| Max Distance to Servers | Up to 100 ft (30.5 m) |
| Network Interfaces | (2) RJ-45 Ethernet (10/100 Mbps) |
| USB Ports | 1 |
| PS/2 Ports | Yes |
| Serial Ports | (2) RJ45 serial |
| Input Voltage | 120V / 230V AC |
| Rack Height | 1U |
| Mounting Type | 19-inch rack mount |
| Weight | ~28.5 lb (≈ 12.9 kg) |
| Operating Systems | Windows, Linux |
| Security | AES encryption, HTTPS, RADIUS/LDAP |
