Detailed Specifications
EATON B163-001 4K 60Hz HDMI DisplayPort USB-C AV over IP Transmitter Compatible Tripp Lite
Overview
The EATON B163-001 is a professional AV over IP transmitter designed to transmit 4K 60Hz audio/video over standard Cat5e/Cat6 network cabling. It supports HDMI, DisplayPort and USB-C source inputs and works with B163-100 receivers for point-to-point or multicast installations.
The transmitter supports visually lossless compression, approximately 800 Mbps video bitrate and approximately 2 ms latency at 2160p. It also provides local HDMI output, Gigabit Ethernet connectivity, USB, RS-232 and IR control interfaces.
Key Features
- Brand / Manufacturer: EATON
- Compatible Brand: Tripp Lite
- Model: B163-001
- Product Type: AV over IP Transmitter
- Maximum Resolution: 4K @ 60Hz
- Network: Gigabit Ethernet
- Transmission Distance: Up to 328 ft / 100 m
- Cable: Cat5e / Cat6
- Video Inputs: HDMI, DisplayPort, USB-C
- Local Video Output: HDMI
- Video Compression: Visually Lossless
- Video Bitrate: Approximately 800 Mbps
- Latency: Approximately 2 ms at 2160p
- HDCP: 2.3, backward compatible with 2.2/1.4
- HDR: HDR10 and Dolby Vision
- Color Depth: Up to 12-bit
- Chroma: RGB / 4:4:4 / 4:2:2
- Network Mode: Unicast / Multicast
- USB: Micro-USB host
Specifications
| Specification | Details |
|---|
| Manufacturer | EATON |
| Compatible Brand | Tripp Lite |
| Model | B163-001 |
| Product Type | AV over IP Transmitter |
| Maximum Resolution | 4K @ 60Hz |
| Network Interface | Gigabit Ethernet |
| Transmission Distance | Up to 328 ft / 100 m |
| Recommended Cable | Cat5e / Cat6 |
| HDMI Input | 1 × HDMI |
| DisplayPort Input | 1 × DisplayPort |
| USB-C Input | 1 × USB-C |
| Local HDMI Output | 1 × HDMI |
| Video Bitrate | Approx. 800 Mbps |
| Latency | Approx. 2 ms at 2160p |
| Compression | Visually Lossless |
| HDCP | 2.3 / 2.2 / 1.4 |
| HDR Support | HDR10 / Dolby Vision |
| Color Depth | Up to 12-bit |
| Chroma Support | RGB / 4:4:4 / 4:2:2 |
| Network Mode | Unicast / Multicast |
| RS-232 | Yes |
| IR Control | Bi-directional |
| Compatible Receiver | B163-100 |
| Compliance | TAA, RoHS, REACH, WEEE, FCC |
