The StarTech IES1G52UP12V is a ruggedized, unmanaged Gigabit Ethernet switch designed for harsh industrial environments. It features five ports in total: four Gigabit PoE+ ports and one dedicated Gigabit SFP slot for long-distance fiber uplinks. This switch is specifically engineered for deployments where standard 48V power is unavailable, as its integrated power booster allows it to accept 12V to 56V DC input while still delivering full 30W PoE+ (802.3at) to connected devices.
Housed in a compact, IP30-rated metal enclosure, the unit is built to withstand extreme temperatures, vibrations, and electromagnetic interference commonly found in factory floors, outdoor surveillance cabinets, and transportation hubs. It supports DIN-rail or wall mounting, providing flexible installation options in space-constrained control panels.
The IES1G52UP12V features redundant power inputs with terminal block connectors to ensure maximum uptime; if the primary power source fails, the switch seamlessly transitions to the secondary source. It is an unmanaged "plug-and-play" device, making it ideal for rapid deployment in edge networks where complex software configuration is not required.
Power booster allows 12V-56V DC input for full 54V PoE+ output.
4x Gigabit PoE+ ports deliver up to 30W per port (120W total budget).
1x Open SFP slot enables flexible fiber optic uplinks for long distances.
IP30-rated metal housing operates in temperatures from -40°C to 75°C.
Redundant terminal block power inputs prevent downtime from power failure.
| Specification | Details |
| Brand | StarTech |
| Part Number | IES1G52UP12V |
| Product Type | Industrial Unmanaged PoE Switch |
| Total Ports | 5 |
| Port Types | 4x RJ45 (PoE+), 1x SFP Slot |
| Data Rate | 10/100/1000 Mbps |
| PoE Standard | IEEE 802.3af (PoE) / 802.3at (PoE+) |
| Max PoE Budget | 120W |
| Input Voltage | 12V to 56V DC (Terminal Block) |
| Enclosure | IP30 Aluminum |
| Operating Temp | -40°C to 75°C (-40°F to 167°F) |
| Mounting | DIN Rail or Wall Mount |
| MTBF | > 500,000 hours |
