The HP 5500 HI Switch Series comprises Gigabit Ethernet switches that deliver outstanding resiliency, security, and multiservice support capabilities at the edge layer of data center, large campus, and metro Ethernet networks. The switches can also be used in the core layer of SMB networks.
With Intelligent Resilient Fabric (IRF) support and available dual power supplies, the HP 5500 HI Switch Series can deliver the highest levels of resiliency and manageability. In addition, the PoE+ models provide up to 1,440 W of PoE+ power with the dual power supply configuration.
| General Information |
|---|
| Brand Name: |
HPE |
| Manufacturer: |
Hewlett Packard Enterprise |
| Manufacturer Part Number: |
JG542A |
| Manufacturer Website Address: |
http://www.hpe.com |
| Product Model: |
5500-48G-POE+-4SFP HI |
| Product Name: |
5500-48G-PoE+-4SFP HI Switch with 2 Interface Slots |
| Product Series: |
5500 HI |
| Product Type: |
Layer 3 Switch |
| I/O Expansions |
|---|
| Expansion Slot Type: |
SFP |
|
SFP+ |
| Number of SFP Slots: |
4 |
| Number of SFP+ Slots: |
2 |
| Number of Total Expansion Slots: |
8 |
| Shared SFP Slot: |
No |
| Interfaces/Ports |
|---|
| Bypass: |
No |
| LRE Port: |
No |
| Management Port: |
Yes |
| Modular: |
Yes |
| Number of PoE+ (RJ-45) Ports: |
48 |
| Port/Expansion Slot Details: |
10 Gigabit Ethernet |
|
48 x Gigabit Ethernet Network |
|
Gigabit Ethernet |
| Token Ring Port: |
No |
| Total Number of Network Ports: |
48 |
| Management & Protocols |
|---|
| Manageable: |
Yes |
| Management: |
- Web-based Management
- VLAN
- QoS
- SNMP v1, v2c, v3
- RMON 1, 2, 3, 9
- DHCP
- MIB II
|
| Media & Performance |
|---|
| Ethernet Technology: |
Gigabit Ethernet |
| Media Type Supported: |
Twisted Pair |
| Network Technology: |
10/100/1000Base-T |
| Memory |
|---|
| Flash Memory: |
512 MB |
| Memory Technology: |
SDRAM |
| Standard Memory: |
1 GB |
| Miscellaneous |
|---|
| Certifications & Standards: |
- Web-based Management
- VLAN
- QoS
- SNMP v1, v2c, v3
- RMON 1, 2, 3, 9
- DHCP
- MIB II
IEEE Standards:
- 802.1ad
- 802.1D
- 802.1p
- 802.1Q
- 802.1w
- 802.3ab
- 802.3ad
- 802.3ae
- 802.3af
- 802.3i
- 802.3u
- 802.3x
- 802.3z
Safety:
- UL 60950-1
- EN 60825-1
- EN 60825-2
- IEC 60950-1
- EN 60950-1
- CAN/CSA-C22.2 No. 60950-1
- FDA 21 CFR
- AS/NZS 60950-1GB 4943
Emissions:
- N 55022 Class A
- CISPR 22 Class A
- EN 55024
- ICES-003 Class A
- CISPR 24
- AS/NZS CISPR 22 Class A
- EN 61000-3-2
- EN 61000-3-3
- GB9254
- VCCI-3 CLASS A
- VCCI-4 CLASS A
- ETSI EN 300 386
- FCC Part 15 (CFR 47) CLASS A
- YD/T993
|
| Environmental Certification: |
RoHS |
| Environmentally Friendly: |
Yes |
| Package Contents: |
- 5500-48G-PoE+-4SFP HI Switch with 2 Interface Slots
- Mounting Hardware
|
| Network & Communication |
|---|
| Layer Supported: |
3 |
| Physical Characteristics |
|---|
| Color: |
Black |
| Compatible Rack Unit: |
1U |
| Depth: |
18.1" |
| Form Factor: |
Rack-mountable |
| Height: |
1.7" |
| Weight (Approximate): |
23.15 lb |
| Width: |
17.3" |
| Power Description |
|---|
| PoE (RJ-45) Port: |
Yes |
| Power Source: |
Power Supply |
| Redundant Power Supply Supported: |
Yes |
| Warranty |
|---|
| Limited Warranty: |
Lifetime |
| Basic |
|---|
| Brand Name: |
HPE |
| Ethernet Technology: |
Gigabit Ethernet |
| Expansion Slot Type: |
SFP+ |
| Form Factor: |
Rack-mountable |
| Layer Supported: |
3 |
| Manageable: |
Yes |
| Media Type Supported: |
Twisted Pair |
| Network Technology: |
10/100/1000Base-T |
| Number of Total Expansion Slots: |
8 |
| PoE (RJ-45) Port: |
Yes |
| Port/Expansion Slot Details: |
10 Gigabit Ethernet |
| Power Source: |
Power Supply |
| Product Family: |
5500 HI |
| Product Type: |
Layer 3 Switch |
| Redundant Power Supply Supported: |
Yes |
| Total Number of Network Ports: |
48 |
