The HPE JG510A 5900 Switch Series are low-latency 1/10GbE data center top-of-rack (ToR) switches. Perfect for deployment at server access layer in large and medium sized enterprises. These switches may also be used in campus core/distribution layers where higher performance 40GbE connectivity is required with 10GbE links. Virtualized applications and server-to-server traffic require ToR switches that meet the needs for higher-performance server connectivity, convergence, virtual environment support, and low-latency. Optional Intelligent Management Center (IMC) Software Platform for network management.
Product Features JG510A
- Ultra-low-latency and Wire Speed for Demanding Applications
The HPE JG510A FlexFabric 5900 Switch Series provides high density 10/100/1000/10000BASE-T, or fiber ports for high-performance and flexible deployments.
All ports support full L2/L3 features, IPv4/IPv6 dual stack, OpenFlow and TRILL for high scalability and Software-defined Network (SDN) support.
Intelligent Resilient Fabric (IRF) for simpler management, faster re-convergence and business agility. - High-Performance Data Center Switching
The HPE JG510A FlexFabric 5900 Switch Series delivers 1.28 Tbps switching capacity for the most demanding applications.
Supports up to 952 MPPS throughput for data intensive environments.
Low latency, under a 1.5 us 10GbE latency, provides increased performance.
Four 40GbE QSFP+ ports for blazing fast uplinks. - Business Agility and Resilience with Comware 7
The HPE JG510A FlexFabric 5900 Switch Series delivers IRF < 50 msec convergence time enabling faster application response times.
In Service Software Update (ISSU) enables high availability with updates accomplished without a reboot or power cycle, in the background. - Simplicity and Lower TCO
The HPEJG510A FlexFabric 5900 Switch Series simplifies switch management by up to 88% with IRF.
No extra hidden cost with simple one license per switch for all OS features.
All switch ports are active and ready to use without need for activation licenses.
Automate tedious tasks with SDN and reclaim wasted resources.
What's in the Box JG510A
- (1) HPE JG510A FlexFabric 5900AF-48G-4XG-2QSFP+ Switch
Specification JG510A:
Device Type | Switch - 48 ports - managed |
Enclosure Type | Rack-mountable 1U |
Subtype | Gigabit Ethernet |
Ports | 48 x 10/100/1000 + 4 x 10 Gigabit Ethernet / 1 Gigabit Ethernet SFP+ + 2 x 40 Gigabit QSFP+ |
Performance | Throughput: 250 Mpps ¦ Routing/switching capacity: 336 Gbps |
Capacity | IPv4 routing table entries: 16000 ¦ IPv6 routing table entries: 8000 |
MAC Address Table Size | 128K entries |
Jumbo Frame Support | Yes |
Routing Protocol | OSPF, BGP-4, RIP-1, RIP-2, BGP, VRRP, OSPFv2, static IP routing, ECMP |
Remote Management Protocol | SNMP 1, Telnet, SNMP 3, SNMP 2c, CLI |
Authentication Method | Secure Shell (SSH), Secure Shell v.2 (SSH2) |
Features | DHCP support, ARP support, VLAN support, port mirroring, DiffServ support, Broadcast Storm Control, IPv6 support, Weighted Random ... |
Compliant Standards | IEEE 802.1D, IEEE 802.1Q, IEEE 802.1p, IEEE 802.3ad (LACP), IEEE 802.1w, IEEE 802.3ae, IEEE 802.1s, IEEE 802.1ab (LLDP) |
RAM | 2 GB SDRAM |
Flash Memory | 512 MB |
Interfaces | 48 x Gigabit LAN 10Base-T/100Base-TX/1000Base-T ¦ 4 x Gigabit / 10Gbit LAN 10Gb Ethernet / 1Gb Ethernet - SFP+ - SFP+ ¦ 2 x 40Gbit ... |
Power Device | Internal power supply - hot-plug |
Installed Qty | 0 (installed) / 2 (max) |
Power Redundancy | Optional |
Power Redundancy Scheme | 1+1 (with optional power supply) |
Voltage Required | AC 120/230 V (50/60 Hz) |
Power Consumption Operational | 260 Watt |
Width | 17.3 in |
Depth | 18.1 in |
Height | 1.7 in |
Weight | 28.66 lbs |
Service & Support | Limited warranty - advance parts replacement - 1 year |
Min Operating Temperature | 32 °F |
Max Operating Temperature | 113 °F |
Humidity Range Operating | 10 - 90% (non-condensing) |
Product Description | HPE 5900AF-48G-4XG-2QSFP+ Switch - switch - 48 ports - managed - rack-mountable |
Power | AC 120/230 V (50/60 Hz) |
Dimensions (WxDxH) | 17.3 in x 18.1 in x 1.7 in |
manufacturer | Hewlett Packard Enterprise |
