HPE 5130 48G 4SFP+ 1-slot HI Switch - 1 Expansion Slot, 4 Expansion Slot, 48 Network - Manageable View larger

HP FlexNetwork 5130 Series 5130-48G-4SFP+ 48 x Port 1000Base-T + 4 x Ports SFP+ Layer3



In Stock

HP FlexNetwork 5130 Series 5130-48G-4SFP+ 48 x Port 1000Base-T + 4 x Ports SFP+ Layer3


HP, HPE, HPE 5130 switch, HP JH324A, HPE JH324A, JH324A, HPE 5130 48G, HP 5130 48G, HP 5130 48 ports switch, HP 5130 switch, JH324A HP, JH324A port, JH324A Layer 3, JH324A network, JH324A SFP, JH324A Flec, JH324A access, JH324A review, JH324A manual, JH324A datasheet


Detailed Specifications

HP FlexNetwork 5130 Series 5130-48G-4SFP+ 48 x Port 1000Base-T + 4 x Ports SFP+ Layer3 Managed 1U Rack-Mountable Gigabit Ethernet Network HI Switch

Overview JH324A:

The HPE JH324A FlexNetwork 5130 HI Switch Series delivers scalability and resiliency at the access layer of medium and large enterprise campus networks. This FlexNetwork switch supports enterprise class QoS and security, HPE Intelligent Resilient Framework (IRF) stacking, static Layer 3 routing and RIP, dual redundant power supplies, fixed and modular 10GbE uplinks ports, PoE+, ACLs, IPv6 and delivers energy savings with Energy Efficient Ethernet.

The 5130 HI Switch Series can be managed with HPE Intelligent Management Center (IMC) Software for a single view of your entire network.

Features JH324A:

Scalable and Resilient Access Layer Switches The HPE FlexNetwork 5130 HI Switch Series delivers scalability and resiliency for medium and large enterprise networks. It supports stacking, dual power supplies; 10GbE uplinks; static and RIP routing; PoE+; ACLs; IPv6 and power savings. The HPE Intelligent Resilient Framework (IRF) virtualizes up to nine physical switches into one logical device for simpler, flatter, more agile networks. Offers scalable stacking and backhaul capacity with four fixed 10GbE uplinks and slots for two more 10GbE uplinks, including support for 10GBASE-T. Dual, redundant, hot-swappable power supplies keep your network up and running and deliver up to 1440 Watts of PoE+ for powered cameras, phones and wireless access points. No software licensing required. Improved Quality of Service (Q0S) with Traffic Management The HPE FlexNetwork 5130 HI Switch Series supports advanced classifier-based QoS which groups traffic using multiple match criteria based on Layer 2 and 3 information; applies QoS policies such as setting priority level and rate limit to selected traffic on a port, VLAN, or whole switch. Provides traffic prioritization with supported congestion actions include: strict priority (SP) queuing, weighted round robin (WRR), weighted random early detection (WRED), and SP+WRR and traffic policing with Committed Access Rate (CAR) and line rate. Reduce unwanted network traffic with broadcast control allows limitation of broadcast traffic rate to cut down on unwanted network broadcast traffic. Comprehensive Security Control The HPE FlexNetwork 5130 HI Switch Series supports flexible authentication methods including 802.1X and MAC Authentication for greater policy-driven application security. Per-user access control lists (ACLs) provide identity-driven security and access control. ACLs provide IP Layer 2 to Layer 4 traffic filtering and support global ACL, VLAN ACL, port ACL, and IPv6 ACL. Security with encryption of all access methods (CLI, GUI, or MIB) through SSHv2, SSL, and/or SNMPv3, and other features including DHCP protection, IP source guard, dynamic ARP protection and RADIUS/HWTACAS. Supports industry standard MACsec for greater end-point or switch-to-switch security. Single View of the Network The HPE FlexNetwork 5130 HI Switch Series can be seamlessly managed with HPE Intelligent Management Center (IMC) Software to provide end-to-end network transparency with consistent network experience through comprehensive configuration, compliance and policy management. RMON and sFlow provide advanced monitoring and reporting capabilities for statistics, history, alarms and events.

Specifications JH324A:

Product Name: HP FlexNetwork 5130-48G-4SFP+ (JH324A)

Form Factor: 1U Rack-Mountable


  • 48 x 10/100/1000Base-T (RJ-45) ports
  • 4 x SFP+ (10 Gigabit Ethernet) ports

Switching Capacity: Up to 176 Gbps

Forwarding Rate: Up to 131 Mpps

Buffer Size: 4 MB

MAC Address Table Size: 32,000 entries

Routing Table Size: 2000 entries

Management Interface: Web GUI, CLI (Command Line Interface)

Management Protocols: SNMP v1, v2c, v3; RMON; Telnet; SSH; HTTP; HTTPS

Layer Support: Layer 2 and Layer 3

Redundancy Features: Support for redundant power supply and hot-swappable fan modules

Security Features:

  • Access control lists (ACLs)
  • SSH
  • Port security

QoS (Quality of Service) Features:

  • Traffic classification based on CoS (Class of Service)
  • DiffServ (DSCP)
  • Strict priority
  • Weighted Round Robin (WRR) scheduling

Dimensions (H x W x D): 4.4 cm x 44.2 cm x 36.8 cm (1.73 in x 17.4 in x 14.5 in)

Weight: Approximately 6.0 kg (13.23 lbs)

Power Supply: Internal, AC 100/240 V (50/60 Hz)
