HPE OfficeConnect 1420 24G - switch - 24 ports - unmanaged - rack-mountable View larger

HPE OfficeConnect 1420 24G - switch - 24 ports - unmanaged - rack-mountable

JG708B

New

In Stock

HPE OfficeConnect 1420 24G - switch - 24 ports - unmanaged - rack-mountable
×




HP, HPE OfficeConnect 1420 switch, HPE JG708B ABA, HP JG708B ABA, JG708B ABA, JG708B, HPE OfficeConnect 1420 24G, HPE OfficeConnect 1420 24G switc, HPE OfficeConnect 1420 24 ports

$145.00

Detailed Specifications

HPE OfficeConnect 1420 24G - switch - 24 ports - unmanaged - rack-mountable

The HPE OfficeConnect 1420 Switch Series delivers cost effective gigabit Ethernet (1GbE) connectivity offering small businesses 10 times the performance of Fast Ethernet with unmanaged plug-and-play simplicity. The series includes nine models, all with gigabit performance and a choice of key features including PoE+ for powering IP devices, Fiber and 10G uplinks for connectivity to servers and storage. All models support silent fanless operation, automated features for hands off operation and low power consumption. They come with limited lifetime warranty and 24X7 phone support for 90 days.
The HPE OfficeConnect 1420 Switch Series delivers cost effective gigabit Ethernet (1GbE) connectivity offering small businesses 10 times the performance of Fast Ethernet with unmanaged plug-and-play simplicity. The series includes nine models, all with gigabit performance and a choice of key features including PoE+ for powering IP devices, Fiber and 10G uplinks for connectivity to servers and storage. All models support silent fanless operation, automated features for hands off operation and low power consumption. They come with limited lifetime warranty and 24X7 phone support for 90 days

Cost-effective, High-performance GbE Layer 2 Switching

  • The HPE OfficeConnect 1420 Switch Series features gigabit Ethernet (1GbE) connectivity offering small businesses 10 times the performance of Fast Ethernet with unmanaged plug-and-play simplicity.
  • Unmanaged switches offer a cost-effective small business solution for locations needing only basic Layer 2 switching in a flat single tier network.
  • Half-/full-duplex auto-negotiating capability on every port doubles the throughput of every port.

Flexible Choices To Meet Most Basic Layer 2 Networking Design Needs

  • The HPE OfficeConnect 1420 Switch Series includes nine models, all with gigabit performance and a choice of key features including PoE+, Fiber and 10G uplink options.
  • The 1420-24G-2SFP model with SFP uplinks is ideal where gigabit fiber is required, while the 1420-24G-2SFP+ 10G Uplink model with SFP+ uplinks is available where 10GbE is needed.
  • Power over Ethernet (PoE+) models deliver greater efficiency for powering IP phones, wireless access points, or video surveillance cameras without the cost of additional cabling.
  • All HPE OfficeConnect 1420 Switch Series models are fanless for silent operation in office settings and include internal power supplies.
  • Units can be deployed for desktop operation or can be rack mounted.

Automated Features for Hands-off Operation

  • All HPE OfficeConnect 1420 Switch Series models are plug-and-play with zero configuration and no required ongoing administration.
  • This unmanaged PoE+ model delivers fully automated support for powering compatible IP phones, video surveillance cameras or wireless access points.
  • The HPE 1420-24G-2SFP+ 10G Uplink Switch requires no configuration beyond installation of optional 10GbE transceivers to achieve 10GbE speeds. Alternatively, use today with gigabit SFP transceivers if higher performance is merely a future requirement.
  • IEEE 802.1p prioritization and other QoS features automate the preferred handling of high priority traffic, including Differentiated Services Code Point (DSCP) set priorities.
  • The OfficeConnect 1420 Switch Series supports jumbo packets to improve the performance of large data transfers.

Main Features
  • Switch
  • unmanaged
  • 24 x 10/100/1000
  • desktop
  • rack-mountable

Technical Specifications

  • Environmental Parameters
  • 5 - 95% (non-condensing)
  • 5 - 90% (non-condensing)
  • 104 °F
  • 158 °F
  • 32 °F
  • -40 °F

  • Header
  • HPE
  • PC
  • United States
  • English
  • Aruba
  • 1420 24G
  • 1
  • HPE OfficeConnect

  • Interface Provided
  • RJ-45
  • 24
  • 1000Base-T

  • Miscellaneous
  • Black, Gray
  • CISPR 22, CISPR 24, CSA 22.2 No. 60950, EN 60950-1, EN55022, EN55024, FCC Part 15 B Class A, IEC 60950-1, IEC 61000-3-2, IEC 61000-3-3, IEC 61000-4-11, IEC 61000-4-2, IEC 61000-4-3, IEC 61000-4-4, IEC 61000-4-5, IEC 61000-4-6, IEC 61000-4-8, UL 60950-1
  • 1
  • Included

  • Networking
  • IEEE 802.1p, IEEE 802.3, IEEE 802.3ab, IEEE 802.3az, IEEE 802.3i, IEEE 802.3u, IEEE 802.3x
  • Wired
  • Auto-negotiation, Auto-uplink (auto MDI/MDI-X), DiffServ Code Point (DSCP) support, Fanless, Flow control, Full duplex mode, Half duplex mode, Jumbo Frames support, Mini Jumbo Frame support, Quality of Service (QoS), Type of Service (ToS)
  • Desktop, Rack-mountable
  • 9216 bytes
  • 8192 entries
  • No
  • 24
  • PoE+
  • Link/activity, Port duplex mode, Port transmission speed, Status
  • Network hubs and switches
  • Gigabit Ethernet
  • Switch

  • Power Device
  • 300 mA
  • 50/60 Hz
  • AC 120/230 V
  • 16 Watt
  • Internal power supply

  • Service
  • Lifetime
  • Advance parts replacement
  • Limited warranty

  • Dimensions & Weight
  • 6.8 in
  • 1.7 in
  • 6.61 lbs
  • 17.3 in

  • Service & Support
  • Limited lifetime warranty

  • Flash Memory
  • 1 MB

  • Performance
  • Switching capacity
  • 48 Gbps
  • Throughput
  • 35.7 Mpps

  • Ports
  • 24
  • 10/100/1000
