The past several decades in networking have been defined by static, closed networking solutions designed for the clientserver era. The Aruba JL366A CX 8400 campus core and aggregation switch is a game-changing solution offering a flexible and innovative approach to dealing with the new application, security and scalability demands of the mobile-cloud and IoT era. The Aruba JL366A CX 8400 also serves as a data center switch in either a core/aggregation or a leaf/spine topology.
The Aruba JL366A 8400 provides carrier class high availability with industry-leading line rate 10GbE/25GbE/40GbE/100GbE connectivity in a compact 8 slot chassis. It provides up to 19.2 Tbps of switching capacity based on a fully resilient design that includes redundant fabric, management, power and fans to create a resilient, highly available network that is ideal for the most demanding campus core and data center networks.
Key Features :
- High performance 19.2 terabits per second switching (1.2Tbps/slot) capacity
- Carrier-class high availability with Aruba JL366A Virtual Switching Extension (VSX), redundant management, power, and fabric
- Aruba JL366AOS-CX enables automation and programmability using built-in REST APIs and Python scripts
- Intelligent monitoring and visibility with Aruba JL366A Network Analytics Engine
- Dynamic VXLAN with BGP-EVPN for deep segmentation in data center and campus networks
- One touch deployment with the Aruba JL366A CX Mobile App
- Aruba JL366A NetEdit support for automated configuration and verification
- Advanced Layer 2/3 feature set includes BGP, OSPF, VRF, and IPv6
- Compact 8U chassis with high density, line rate 10GbE/40GbE/100GbE connectivity
Specifications :
Product Name | Aruba JL366A 8400X 6-Port 40GbE/100GbE QSFP28 Advanced Module |
Manufacturer Part Number | JL366A |
Product Type | Expansion Module |
Ethernet Technology | 100 Gigabit Ethernet |
Media Type Supported | Optical Fiber |
Network Technology | 100GBase-X |
Number of Total Expansion Slots | 6 |
Expansion Slot Type | QSFP28 |
Compatibility | Aruba JL366A 8400X Switch Series |
