APC ACDC2507 NetShelter Aisle Containment Roof Height Adapter 700 mm View larger

APC ACDC2507 NetShelter Aisle Containment Roof Height Adapter 700 mm

ACDC2507

New

Steel roof‑height adapter (700 mm) that upgrades a 42U SX NetShelter rack into
×




Detailed Specifications

APC ACDC2507 – 700 mm Roof‑Height Adapter (42U SX → 45U SX)

Overview

The APC ACDC2507 is a structural adapter used in NetShelter aisle‑containment systems to increase the height of a 42U SX rack by 700 mm, effectively turning it into a 45U SX profile. This is particularly useful when a row’s containment ceiling or duct infrastructure was designed for taller racks — instead of replacing the rack, you simply mount this adapter to maintain alignment and preserve the thermal seal. It's widely used in retrofit scenarios where racks need to match existing containment geometry without unnecessary cost or complexity.

Key Features

  • Adds 700 mm of vertical height, converting a 42U SX rack to 45U SX height.

  • Steel construction provides rugged, load-bearing support.

  • Black powder‑coated finish matches NetShelter enclosure aesthetics.

  • RoHS and REACH compliant for environmental performance.

  • Covered by a 5-year limited warranty via APC’s containment accessory policy.

Technical Specifications

SpecificationDetail
Brand APC by Schneider Electric
Part Number ACDC2507
Product Type Roof‑Height Adapter / Rack Extension
Height Increase 700 mm (≈ 27.6 in)
Compatible Rack 42U SX → 45U SX
Width ~697 mm (~27.44 in)
Depth ~1069 mm (~42.09 in)
Height (Adapter Body) ~132 mm (13.2 cm)
Weight ~11.83 kg (26.08 lb)
Material / Finish Steel, black powder coat
Environmental Compliance RoHS, REACH
Warranty 5 Years (limited)
