Detailed Specifications
Jabra 9170195 Engage 40 Mono Wired Headset
Overview
The Jabra 9170195 identifies a specific configuration variant of the Jabra Engage 40 professional wired mono headset system. This enterprise communication endpoint is engineered for high-density customer service operations, commercial call center floors, and intensive unified communications environments. System architects and procurement teams deploy this hardware to optimize vocal transmission clarity while filtering intrusive background acoustics, enabling operators to maintain absolute environmental awareness of their physical workspace.
The communication device functions through an advanced dual-microphone configuration, combining an acoustic noise-canceling element with a precise voice-isolation processing circuit. This internal configuration isolates live human speech patterns while dampening ambient floor noise, keyboard clicks, and surrounding conversational bleed. To protect agent hearing, the internal signal path integrates localized dynamic acoustic limits that automatically suppress dangerous incoming decibel spikes without interrupting active digital data streams.
This endpoint interfaces directly with corporate workstations, enterprise softphones, thin-client computers, and virtual desktop infrastructures (VDI). It utilizes a monaural single-ear over-the-head form factor featuring an angled, breathable ear cushion designed to reduce localized thermal and mechanical pressure over continuous multi-hour shifts. Operating over a hardwired digital bus architecture, the terminal guarantees stable audio streaming free from the radio frequency (RF) signal drops or battery constraints of wireless setups.
System synchronization within local workstation architectures relies on standard driver frameworks compatible with leading cloud telephony platforms and softphone engines. Centralized device control, mass firmware updates, and remote profile configurations are handled globally through Jabra Xpress and Jabra Direct administration consoles. Structurally, the peripheral is built with high-durability polymers and reinforced stress points to survive the severe mechanical wear of continuous contact center use.
Key Features
Dual-microphone noise-isolating array processes clear vocal transmission paths
Advanced real-time hearing protection actively flattens incoming signal spikes
Integrated multi-angle busylight automatically flags live agent call status
Lightweight mono mechanical framing preserves constant immediate spatial awareness
Certified compatibility with leading UC software and softphone environments
Specifications
| Parameter | Technical Specification |
| Brand | Jabra |
| Part Number | 9170195 |
| Product Type | Mono Wired Headset |
| Connectivity Technology | Wired USB Digital Interface |
| Audio Output Mode | Mono (Monaural Single-Ear Configuration) |
| Speaker Driver Size | 20 mm Dynamic |
| Speaker Bandwidth (Speak Mode) | 50 Hz-7000 Hz |
| Speaker Bandwidth (Music Mode) | 50 Hz-20000 Hz |
| Microphone Type | Dual MEMS Noise-Canceling Microphone Array |
| Microphone Bandwidth | 100 Hz-14000 Hz |
| Hearing Protection | PeakStop 118 dBA, G616 Protection, IntelliTone 2.0 |
| Status Indicator | Integrated Busylight Matrix |
| Device Management Platforms | Jabra Direct, Jabra Xpress |
| Form Factor | On-Ear Adjustable Headband |
| Chassis Materials | High-Durability Engineered Plastics with Reinforced Joints |
| Weight | 1.6 oz / 45 g (Excluding Cabling Assembly) |
