Detailed Specifications
Jabra 9170203 Engage 50 II Mono Wired Headset
Overview
The Jabra 9170203 identifies a specific configuration variant of the Jabra Engage 50 II professional wired mono headset system. This single-sided communication endpoint is engineered for intensive customer service operations, high-volume centralized contact centers, and enterprise unified communications infrastructure. Deployment teams issue this hardware to eliminate local environment acoustic bleed from entering the communication line while enabling operators to maintain physical situational awareness of their immediate corporate workspace.
The communication terminal operates via an advanced, software-integrated 3-microphone array that isolates voice signals from surrounding ambient floor noise. This microphone framework works alongside native Engage+ analytical software to process physical parameters×including microphone boom positioning and local noise levels×rendering real-time diagnostic indicators directly to the operator's desktop interface. For auditory protection, the internal signal path incorporates digital protection systems that actively cap incoming audio spikes above safe baseline thresholds.
This hardware component interfaces with enterprise desktop environments, virtualized desktop infrastructures (VDI), and automated dialing networks. It functions entirely through a physical digital bus interface, deploying a lightweight form factor featuring an angled ear cushion designed to reduce localized mechanical pressure during continuous multi-hour production windows. The architecture provides true monaural audio routing, reinforcing communication performance without completely isolating the agent from local team interactions.
System synchronization within local workstation architectures relies on standard driver frameworks compatible with major cloud telephony systems and softphone endpoints. Centralized device control, firmware patching, and remote profiling are executed globally through management platforms like Jabra Xpress and Jabra Direct. Structurally, the assembly utilizes a high-durability strain-relief connector system, ensuring stable, long-term operation through repeated mechanical connections.
Key Features
Three-microphone digital array optimizes precise vocal extraction algorithms
Real-time acoustic analysis and tracking powered via Engage+ software
Smart inline controller unit handles volume tracking and call state toggles
Integrated omnidirectional busylight automatically flags active call status
Lightweight mono mechanical framing preserves constant immediate spatial awareness
Specifications
| Parameter | Specification |
| Brand | Jabra |
| Part Number | 9170203 |
| Product Type | Mono Wired Headset |
| Connectivity Technology | Wired USB Digital Interface |
| Audio Output Mode | Mono (Monaural Single-Ear Configuration) |
| Microphone Type | 3-Microphone Array (Digital MEMS) |
| Microphone Bandwidth | 100 Hz-14000 Hz |
| Speaker Bandwidth | 50 Hz-20000 Hz (Speech Mode / Music Mode) |
| Hearing Protection | PeakStop 118 dBA / IntelliTone 2.0 |
| Device Management | Jabra Direct, Jabra Xpress, Engage+ |
| Form Factor | On-Ear Headband |
| In-Line Controls | Call Answer/End, Volume Up/Down, Mute, Busylight Toggle |
| Status Indicator | Multi-Angle Integrated Busylight |
| Cabling Architecture | Reinforced Shielded Cable with Breakaway Protection |
| Weight | 1.8 oz / 53 g (Excluding Cable Assembly) |
