The StarTech ST12MHDLAN4R is an additional receiver unit for the ST12MHDLAN4K (or ST12MHDLAN4) HDMI over IP distribution system. This receiver allows you to extend a 4K 30Hz HDMI signal over your local area network (LAN) using standard Cat5e or Cat6 cabling. By adding multiple ST12MHDLAN4R units to your network, you can scale your video distribution to multiple displays, making it a perfect solution for large-scale digital signage, corporate presentations, and educational visual arrays.
When used with a managed Gigabit switch (with IGMP support), the system can easily scale from a simple point-to-point extension to a complex multipoint-to-multipoint configuration. The receiver includes a convenient video wall function, allowing you to combine multiple displays into a single large visual surface with easy management through the intuitive web interface or mobile app.
For remote control flexibility, the ST12MHDLAN4R supports infrared (IR) extension, allowing you to control your video source from the display location. The unit's durable aluminum housing and included mounting hardware ensure a professional and secure installation in a variety of environments.
Receives 4K 30Hz HDMI video over a Gigabit LAN or direct Cat5e/Cat6 link.
Fully compatible with the ST12MHDLAN4K (Transmitter) for scalable distribution.
Supports video wall configurations with easy-to-use software management.
Includes IR extension for remote control of the HDMI source device.
Rugged aluminum enclosure with professional mounting options.
| Specification | Details |
| Brand | StarTech |
| Part Number | ST12MHDLAN4R |
| Product Type | HDMI over IP Receiver |
| Max Resolution | 4K (3840x2160) @ 30Hz |
| Max Distance | 100 m (330 ft) per segment |
| Audio Support | 7.1 Surround Sound |
| Cabling Type | Cat5e / Cat6 |
| Network Support | Gigabit Ethernet (1000Base-T) |
| Protocol | IP / UDP |
| IR Extension | Yes |
| Material | Aluminum |
| Operating Temp | 0°C to 40°C (32°F to 104°F) |
