Detailed Specifications
The Seagate ST500LM034 is a 500GB internal hard disk drive from the BarraCuda Pro 2.5-inch family. Designed for compatible laptops and compact computer systems, it features a 7200 RPM spindle speed, 128MB cache, and a SATA 6Gb/s interface. Its compact 7mm height makes it suitable for compatible systems designed for slim 2.5-inch hard drives.
Key Features
- 500GB storage capacity: Provides space for operating systems, applications, documents, and personal files.
- 7200 RPM spindle speed: Supports responsive storage performance for everyday computing tasks.
- 128MB cache: Helps manage data transfers and drive operations.
- SATA 6Gb/s interface: Connects to compatible SATA controllers and drive bays.
- Slim 7mm design: Fits compatible 2.5-inch drive bays that support this height.
Typical Applications
- Compatible laptops and notebook computers
- Computer upgrades and storage replacements
- Compact systems supporting 2.5-inch SATA HDDs
- Compatible external enclosures with SATA drive support
Technical Specifications
| Brand | Seagate |
|---|
| Part Number / MPN | ST500LM034 |
|---|
| Product Type | Internal Hard Disk Drive |
|---|
| Product Family | BarraCuda Pro |
|---|
| Capacity | 500GB |
|---|
| Form Factor | 2.5-inch |
|---|
| Height | 7mm |
|---|
| Spindle Speed | 7200 RPM |
|---|
| Cache | 128MB |
|---|
| Interface | SATA 6Gb/s |
|---|
| Maximum Sustained Data Transfer Rate | Up to 160MB/s |
|---|
| Recording Technology | Shingled Magnetic Recording (SMR) |
|---|
| Logical / Physical Sector Size | 512 bytes / 4096 bytes |
|---|
| Operating Voltage | 5V |
|---|
| Operating Temperature | 0°C to 60°C |
|---|
Compatibility and Installation
This drive is intended for computers and enclosures that support 2.5-inch SATA hard drives. Before purchasing, verify the available drive-bay height, SATA connection, supported capacity, and device compatibility. The SATA 6Gb/s interface is backward-compatible with supported older SATA interfaces, although actual transfer speeds depend on the host system and workload.
DC Supplies Product Note
Confirm the complete model number ST500LM034 before ordering or replacing an existing drive. Do not confuse this model with other Seagate 500GB drives, as spindle speed, physical dimensions, and specifications may differ.
Frequently Asked Questions
What is the capacity of the Seagate ST500LM034?
This drive provides 500GB of storage capacity.
What interface does this hard drive use?
It uses a SATA 6Gb/s interface and requires a compatible SATA connection.
What is the spindle speed?
The drive operates at 7200 RPM.
Will it fit in every laptop?
No. Check that your laptop supports 2.5-inch SATA hard drives and a 7mm drive height before purchasing.
Is this a solid-state drive?
No. The ST500LM034 is a mechanical hard disk drive (HDD), not an SSD.
