Detailed Specifications
NETGEAR GS752TXUP-300NAS 48-Port Gigabit PoE Smart Switch
Overview :
The NETGEAR GS752TXUP-300NAS is a 48-port Gigabit Ethernet Smart Switch with PoE+ and PoE++ support and four 10G SFP+ uplink ports. The -300NAS SKU is the North American/Latin American variant of the GS752TXUP platform.
It provides 48 x 10/100/1000BASE-T ports, with 32 ports supporting IEEE 802.3at PoE+ and 16 ports supporting IEEE 802.3bt PoE++. The switch provides a 640W total PoE budget, 176Gbps switching bandwidth, and 130.94Mpps forwarding performance.
The switch is intended for rack-mounted SMB, campus, surveillance, voice, wireless, and converged-network deployments requiring substantial PoE capacity and 10GbE uplinks. It includes VLAN routing, dynamic VLAN assignment, static routing, QoS, LACP, IGMP/MLD snooping, DHCP snooping, and security controls. It is not appropriate where a basic unmanaged switch is sufficient or where higher-speed than 10GbE uplinks is required.
Key Features :
- 48 Gigabit ports provide high-density wired connectivity
- 640W PoE budget supports demanding powered devices
- 16 PoE++ ports deliver higher-power device support
- Four 10G SFP+ ports provide high-speed uplinks
- Smart management supports VLANs, routing, QoS and security
Specifications :
| Specification | Details |
|---|
| Brand | NETGEAR |
| Part Number | GS752TXUP-300NAS |
| Product Type | 48-Port Gigabit PoE++ Smart Switch |
| Ethernet Ports | 48 x 10/100/1000BASE-T RJ45 |
| PoE+ Ports | 32 x IEEE 802.3at |
| PoE++ Ports | 16 x IEEE 802.3bt |
| SFP+ Ports | 4 x 1G/10G SFP+ |
| PoE Power Budget | 640W |
| Switching Bandwidth | 176Gbps |
| Forwarding Rate | 130.94Mpps |
| MAC Address Table | 16K entries |
| Packet Buffer | 1.5MB |
| VLAN Capacity | 512 VLANs |
| Jumbo Frames | 10KB |
| Form Factor | Rack-mountable / Desktop |
| Management | Smart / optional Insight cloud management |
