HPE P26255-001 BCM57416 Network Ethernet Adapter 2 Port View larger

HPE P26255-001 BCM57416 Gigabit Ethernet Network Adapter 2-Port

P26255-001

New

Dual-port 10 GbE BASE-T network adapter
×




Detailed Specifications

HPE P26255‑001 Broadcom BCM57416 10Gb BASE‑T Adapter

Overview

The HPE P26255‑001 is a dual-port 10 Gb Ethernet adapter built around the Broadcom BCM57416 controller. It provides high throughput networking over two RJ‑45 BASE‑T ports, making it suitable for virtualized servers, storage traffic, and data‑intensive workloads. The card uses a PCI Express 3.0 ×8 interface for efficient host connection while reducing CPU load through advanced offload features. It is designed for HPE ProLiant platforms and can be deployed in both data center and enterprise environments where cost-effective 10 Gb copper networking is required.

Key Features

  • Two 10 GbE BASE‑T (RJ‑45) ports

  • Broadcom BCM57416 controller for reliable performance

  • Offload support including TCP/IP, SR-IOV, RoCE

  • PCIe 3.0 ×8 interface for full 8‑lane bandwidth

  • Low‑profile/half-height form factor for dense server deployment

Technical Specifications

SpecificationDetails
Brand HPE
Part Number P26255‑001
Product Type Ethernet network adapter
Controller Broadcom BCM57416
Ports 2 × 10 Gb BASE‑T RJ‑45
Bus Interface PCI Express 3.0 ×8
Offload Features TCP/IP, SR-IOV, RoCE, VLAN, VXLAN/NVGRE
Data Rates 10 Gb/s per port
Power Consumption ~7 W typical
Form Factor Low-profile, half-height plug-in card
Compatibility HPE ProLiant servers (Gen10 / Gen10 Plus)
Firmware Digitally signed firmware for secure boot / root of trust
Operating Systems Broad support via HPE drivers (Windows, Linux)
Weight ~5.0 lbs (shipping spec)
Diagnostics Supports NIC-level diagnostics via HPE tools
Security Secure Boot, signed firmware
Warranty HPE standard adapter warranty
