HPE 817746-B21 10Gb 2-Port 562FLR-T Network Adapter View larger

HPE 817746-B21 10Gb 2-Port 562FLR-T Network Gigabit Ethernet Adapter

New

Dual-port 10 Gb/s RJ-45 server adapter
×




  • New

Detailed Specifications

HPE 817746-B21 Ethernet 10Gb 2-Port 562FLR-T Adapter

Overview

The HPE 817746-B21 is a server network adapter offering two 10 Gb/s RJ-45 (10GBASE-T) ports in a FlexibleLOM 562FLR-T form-factor, designed for HPE Gen10 ProLiant servers. Each port can deliver full line-rate traffic and the adapter delivers up to ~40 Gb/s aggregate bi-directional bandwidth, enabling high-throughput uplinks for virtualised hosts or storage-dense servers. It uses Cat6A/Cat7 copper structured cabling and supports advanced Ethernet features such as link aggregation, flow control, and various QoS standards. With a low power draw (~10.5 W typical) and RJ-45 convenience, it is suited for data-centre or enterprise compute nodes requiring high-speed copper uplinks without fibre optics. The adapter installs in the server’s mezzanine or adapter bay, preserving standard PCIe slots and integrating into existing I/O fabrics for modern workloads.

Key Features

  • 2 × 10 Gb/s RJ-45 (10GBASE-T) ports in one adapter

  • FlexibleLOM 562FLR-T form-factor for HPE Gen10 servers

  • Aggregate bi-directional bandwidth up to ~40 Gb/s

  • Supports copper structured cabling up to ~100 m with Cat6A/Cat7

Technical Specifications

SpecificationValue
Brand HPE
Part Number 817746-B21
Product Type Ethernet 10Gb 2-Port 562FLR-T Adapter
Port Count 2
Supported Link Speeds 10 Gb/s per port
Port Type RJ-45 (10GBASE-T)
Host Interface FlexibleLOM (562FLR-T) or equivalent adapter slot
Typical Aggregate Bandwidth Up to ~40 Gb/s bi-directional
Power Consumption ~10.50 W typical / ~14.50 W maximum
Operating Temperature Range 5 °C to 60 °C
Weight ~0.20 lb (~0.09 kg) – estimation
Compatible Server Platforms HPE ProLiant Gen10 series
Cable Type Cat6A/Cat7 copper up to ~100 m
Advanced Features Link aggregation, flow control, QoS standards
