StarTech BNDTB1394B3 3 Port FireWire 800 PCIe Card

StarTech BNDTB1394B3 3 Port FireWire 800 PCIe Card

Overview

The StarTech BNDTB1394B3 is a high-performance PCI Express expansion card designed to add legacy high-speed serial connectivity to modern desktop computers and servers. It features a triple-port configuration, providing two FireWire 800 (1394b) ports and one FireWire 400 (1394a) port, enabling simultaneous connection of multiple legacy peripherals.

This adapter is engineered for professionals in digital media, data recovery, and industrial automation who require reliable data transfer from external hard drives, DV camcorders, and high-resolution digital cameras. Built with the TI XIO2213B chipset, it ensures maximum compatibility across Windows, macOS, and Linux environments, supporting "plug-and-play" installation without the need for additional software in most modern operating systems.

The card utilizes a PCIe x1 interface, making it compatible with any PCIe slot from x1 to x16. It includes a standard profile bracket pre-installed and comes with an optional low-profile bracket, allowing for deployment in small form factor (SFF) workstations or slimline desktop chassis.

Key Features

• Triple-port design: 2x FireWire 800 (9-pin) and 1x FireWire 400 (6-pin).

• TI XIO2213B chipset provides native support and high-speed stability.

• Supports data transfer rates up to 800Mbps for high-bandwidth devices.

• Includes both standard and low-profile brackets for versatile installation.

• Compliant with PCI Express 1.1 specifications for broad slot compatibility.

Specifications
