Detailed Specifications
Eaton N844-03M-8LC-P - Fiber-Optic Fan-Out Cable 3 m (OM3)
Overview :
The Eaton N844-03M-8LC-P is a 3-meter (10-ft) multimode fiber-optic fan-out cable that connects a single MTP/MPO connector to eight LC connectors. It is intended for data center or enterprise networking environments where high-speed aggregated fiber links need to split into multiple LC connections for switches, patch panels, or transceivers. It supports OM3 50/125 µm fiber and is rated for 40 GbE (40GBASE-SR4), making it suitable for backbone links or high-density switch-to-patch-panel distribution. The plenum-rated jacket allows installation in plenum air-spaces, meeting fire-safety codes where required. The cable is useful where one needs to fan out a high-density MPO trunk into multiple LC endpoints × for instance, from a backbone trunk to individual switch ports × enabling flexible, modular cabling in data centers or campus fiber deployments.
Key Features
MTP/MPO to 8×LC OM3 fan-out design
Supports 40 GbE (40GBASE-SR4) multimode fiber
3 m (10 ft) length × suitable for rack or row cabling
Plenum-rated jacket for safe air-space installation
50/125 µm fiber core/cladding specification
Technical Specifications
| Parameter | Value |
|---|
| Brand | Eaton (Tripp Lite series) |
| Part Number | N844-03M-8LC-P |
| Product Type | Fiber-Optic Fan-Out Cable |
| Fiber Type | Multimode OM3 |
| Core / Cladding Diameter | 50 / 125 µm |
| Number of Fibers | 8 |
| Cable Length | 3 m (≈10 ft) |
| Connector - End A | 1 × MTP/MPO (female) |
| Connector - End B | 8 × LC (male) |
| Jacket Type | Plenum-rated |
| Data Rate Support | 40 Gbps (40 GbE 40GBASE-SR4) |
| Jacket Color | Aqua |
| Recommended Use | High-density switch to patch panel links |
| Environmental Compliance | RoHS compliant |
| Country of Origin | China |
| Approx. Shipping Weight | 0.17 lbs (≈0.08 kg) |
