EATON B163-100 4K 60Hz HDMI AVoIP Receiver Compatible Tripp Lite
Overview
The EATON B163-100 is a video/audio over IP receiver designed to work with the B163-001 transmitter. It receives HDMI video and audio over a Gigabit Ethernet network and supports 4K at 60Hz for professional AV and IT installations. It can operate in point-to-point unicast or one-to-many multicast configurations through a managed network switch.
The B163-100 supports visually lossless compression, approximately 800 Mbps video bitrate and low latency for demanding 4K applications. It is designed for use with standard Cat5e, Cat6 or Cat6a network cabling and is TAA compliant.
Key Features
- Brand / Manufacturer: EATON
- Compatible Brand: Tripp Lite
- Model: B163-100
- Product Type: Video/Audio Extender Receiver
- Technology: AV over IP
- Video Input: Network / 1GbE
- Video Output: HDMI
- Maximum Resolution: 4K @ 60Hz
- Network: Gigabit Ethernet
- Transmission Medium: Cat5e / Cat6 / Cat6a
- Transmission Distance: Up to 100 m / 328 ft
- Compression: Visually Lossless
- Video Bitrate: Approximately 800 Mbps
- Latency: Approximately 2 ms at 2160p
- HDCP: HDCP 2.3, backward compatible with HDCP 2.2/1.4
- HDR: HDR10 and Dolby Vision
- Color: Up to 12-bit
Specifications
| Specification | Details |
|---|
| Manufacturer | EATON |
| Compatible Brand | Tripp Lite |
| Model | B163-100 |
| Product Type | Video/Audio Extender Receiver |
| Series | B163 |
| Technology | AV over IP |
| Maximum Resolution | 4K @ 60Hz |
| Network Interface | 1GbE |
| Transmission Cable | Cat5e / Cat6 / Cat6a |
| Maximum Distance | 100 m / 328 ft |
| Video Bitrate | Approx. 800 Mbps |
| Latency | Approx. 2 ms at 2160p |
| Compression | Visually Lossless |
| HDCP Support | HDCP 2.3 / 2.2 / 1.4 |
| HDR Support | HDR10, Dolby Vision |
| Color Depth | Up to 12-bit |
| Chroma Support | RGB / 4:4:4 / 4:2:2 |
| Network Mode | Unicast / Multicast |
| Compatible Transmitter | B163-001 |
| TAA Compliant | Yes |
