The Eaton B127A-111-BDTD DisplayPort over Cat6 Extender Kit provides a robust solution for extending high-resolution video and audio signals beyond the limitations of standard cabling. Designed for environments like conference rooms, digital signage installations, and educational facilities, this kit effectively bridges the gap between DisplayPort source devices and monitors. It addresses the common challenge of maintaining crystal-clear 4K video quality over significant distances, ensuring seamless content delivery. This extender kit transmits Ultra HD resolutions up to 3840 x 2160 (4K) at 30 Hz with 4:4:4 chroma subsampling, guaranteeing vibrant and accurate color reproduction crucial for professional presentations or detailed visual content. It supports DisplayPort 1.2a and is HDCP 2.2 compliant, allowing for the secure transmission of protected content. A notable feature is Power over Cable (PoC) technology, which eliminates the need for a separate power supply at the receiver unit, simplifying installation and reducing cable clutter. The transmitter also includes a local HDMI port for convenient monitoring of the extended video signal. Deployment is straightforward with its plug-and-play design, requiring no complex software installation. The compact transmitter and receiver units come with mounting hardware, enabling flexible installation on walls, poles, or within a 19-inch rack. Furthermore, the B127A-111-BDTD kit is TAA (Trade Agreements Act) compliant, making it suitable for government procurement contracts and ensuring adherence to federal purchasing guidelines. The system can be daisy-chained up to four times, extending the total range to an impressive 920 feet (280.4 meters) with additional receiver units, offering scalable solutions for larger installations.
| Specification | Value |
|---|---|
| Brand | Eaton |
| Part Number | B127A-111-BDTD |
| Product Type | DisplayPort over Cat6 Extender Kit |
| Series | Tripp Lite Series |
| Max Video Resolution | 3840 x 2160 (4K) @ 30 Hz |
| Video Standards | DisplayPort 1.2a, HDCP 2.2 |
| Color Subsampling | 4:4:4 Chroma |
| Audio Support | 7.1-channel surround sound (via TOSLINK) |
| Max Extension Distance | 230 ft (70.1 m) |
| Extension Cable Type | Cat6 (or higher) |
| Daisy Chain Capability | Up to 920 ft (280.4 m) with 4 units |
| Local Transmitter Port | HDMI |
| Power Over Cable (PoC) | Yes |
| TAA Compliance | Yes |
| Mounting Options | Wall, Pole, 19-inch Rack (hardware included) |
| Unit Dimensions (H x W x D) | 1.06 x 4.53 x 2.46 in |
| Unit Weight | 0.99 lbs |
