Overview

The Eaton 5PXEBM72RT3UAG2 is a high-capacity, 72 V external battery module (EBM) purpose-built for extending runtime of compatible Eaton 5PX G2 UPS systems (e.g., 2 kVA & 3 kVA models). It occupies a 3U rack/tower form-factor, mounting easily in standard 19-inch enclosures using the supplied rail kit or as a free-standing tower with included bracket. Inside, it houses twelve sealed lead-acid (12 V/9 Ah) batteries pre-wired into a 72 V DC configuration, delivering hours of additional runtime when tied into the UPS chain. Engineers deploy this module when the internal battery bank of the UPS no longer provides the runtime required for servers, network switches, storage gear or remote edge infrastructure. The module features heavy-gauge DC bus cabling, detection-cable support and is certified to global UPS-battery standards (IEC/EN 62040-1/2/3, UL 1778, CSA 22.2) to ensure safe integration into mission-critical racks. With a weight of ~87.5 lb (≈ 39.7 kg) and rail-kit installation, it fits neatly into high-availability IT racks without consuming extra U-space for added runtime. If you’re planning growth, server consolidation or longer fail-over operation on your 2 kVA/3 kVA 5PX G2 platform, this battery module is your runtime extension solution.

Key Features

• Compatible with Eaton 5PX G2 2 kVA & 3 kVA UPS models, enabling drop-in runtime extension without replacing the UPS.

• 72 V sealed lead-acid battery pack (12 × 12 V/9 Ah) pre-wired and configured for high-availability installations.

• 3U rack/tower convertible chassis, saves valuable U-space in racks and allows flexible mounting options.

• Includes rail kit, tower stand brackets and high-current DC connector cables for rapid field deployment.

Specifications
